Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH163
Model Number: LPJK0030A93NL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.09-$1.85
Packaging Details: Tray & Carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Spec: |
ARJP11C-MASD-AB-A-FM2 |
Equivalent: |
LPJK0030A93NL |
Mounting Type: |
90° Angle (Right) |
Interface: |
10/100 Base-T, AutoMDIX |
LED: |
Green - Yellow, Green |
Function: |
Power Over Ethernet (PoE) |
Cross Rf: |
ARJP11C-MASD-AB-A-FM2 = LPJK0030A93NL |
INdustrial: |
LPJK4030A93NL |
Spec: |
ARJP11C-MASD-AB-A-FM2 |
Equivalent: |
LPJK0030A93NL |
Mounting Type: |
90° Angle (Right) |
Interface: |
10/100 Base-T, AutoMDIX |
LED: |
Green - Yellow, Green |
Function: |
Power Over Ethernet (PoE) |
Cross Rf: |
ARJP11C-MASD-AB-A-FM2 = LPJK0030A93NL |
INdustrial: |
LPJK4030A93NL |
| Categories | Rj45 With Integrated POE Magnetics |
|---|---|
| Rj45 Port | 10/100Mbps |
| Series | Single I/O Rj45 |
| Packaging | Tray |
| Part Status | Active by Alternative LPJK0030A93NL / LPJK4030A93NL |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100 Base-T, AutoMDIX, Power over Ethernet (PoE) |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.531" (13.50mm) |
| LED Color | Green - Yellow, Green |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide |
| Tab Direction | Up |
| Contact Material | - |
| Contact Finish | Gold |
| Operating Temperature | 0°C ~ 70°C |
| Contact Finish Thickness | 6µin (0.152µm) |
| Shielded | Yes |
| Housing Material | PBT |
