Home > products > Discrete Magnetic Transformers > L19N002-0 DIP Quad Ports 2.5G BASE –T Gigabit Transformer Modules

L19N002-0 DIP Quad Ports 2.5G BASE –T Gigabit Transformer Modules

Product Details

Place of Origin: China

Brand Name: LINK-PP

Certification: UL,RoHS,Reach,ISO

Model Number: L19N002-0

Payment & Shipping Terms

Minimum Order Quantity: 400/2000/10K/25K

Price: $0.06-$3.2

Packaging Details: T&R

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 3KK/Month

Get Best Price
Highlight:

100/1000base-t filter

,

1000base-t magnetic module

P/N:
L19N002-0
Ethernet:
4 Port 2.5G~5G Base-T
Mounting:
DIP
Application:
EPON/ GPON/ IP Camera
Files:
PDF / Datasheet / 3D / IGS / Step /Stp
Compatible:
L19N002-0=>LPxxxNL
Samples:
Free
P/N:
L19N002-0
Ethernet:
4 Port 2.5G~5G Base-T
Mounting:
DIP
Application:
EPON/ GPON/ IP Camera
Files:
PDF / Datasheet / 3D / IGS / Step /Stp
Compatible:
L19N002-0=>LPxxxNL
Samples:
Free
L19N002-0 DIP Quad Ports 2.5G BASE –T Gigabit Transformer Modules
L19N002-0 DIP Quad Ports 2.5G BASE –T Gigabit Transformer Modules



Manufacturer Series L19N002-0
REACH Compliant Yes
EU RoHS Compliant Yes
China RoHS Compliant Yes
Status Active
Transformer Type DATACOM TRANSFORMER
Application GENERAL PURPOSE
Isolation Voltage 1500.0 V
JESD-609 Code e3
Mfr Package Description ROHS COMPLIANT
Mounting Feature DIP
Number of Functions 4



NOTES:

1.Designed to support application,such as SOHO(ADSL modems),LAN-on-Motherboard(LOM),

   hub and Switches.

2.Meets IEEE 802.3 specification

3.Connector Materials:

   Housing: Thermoplastic PBT+30%G.F UL94V-0

   Contact: Phosphor Bonze C5210R-EH Thickness=0.35mm

   Pins: Brass C2680R-H Thickness=0.35mm

   Shield: SUS 201-1/2H Thickness=0.2mm

   Contact plating: Gold 6 micro-inches min.In contact area.

4.Wave solder tip temperature: 265℃ Max, 5 Sec Max

5.UL Certification: File Number E484635



Application;

Network Cards and Network Controllers

2 Multipurpose Computer Boards

3 Bore and ID Gages

4 Bus Analyzers and Bus Exercisers

5 Cable Assemblies
