Home > products > RJ45 Modular Jack > HR871155C Single Port RJ45 Modular Jack with 10/100 Base-T LPJ0162GDNL

HR871155C Single Port RJ45 Modular Jack with 10/100 Base-T LPJ0162GDNL

Product Details

Place of Origin: China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: HR871155C

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000/25K

Price: $0.05-$1.28

Packaging Details: 50pcs/tray,1200pcs/carton

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 4200K-PCS/Month

Get Best Price
Highlight:

rj-45 ethernet jack

,

modular jacks rj45

Specifications:
HR871155C
PN:
LPJ0162GDNL
Brand:
LINK-PP
Application:
10/100Base-T
LEDs:
YELLOW/GREEN
File:
PDF/3D/ISG/Stp/Step/Datasheet
Specifications:
HR871155C
PN:
LPJ0162GDNL
Brand:
LINK-PP
Application:
10/100Base-T
LEDs:
YELLOW/GREEN
File:
PDF/3D/ISG/Stp/Step/Datasheet
HR871155C Single Port RJ45 Modular Jack with 10/100 Base-T LPJ0162GDNL
HR871156C / LPJ0162GDNL RJ45 Modular Jack 10 / 100Base-T RoHS Compliant


1.10/100 Base-T Applications
2.1X1 Single Port Jack
3. HR871156C Equivalent Specification Compatible Cross PN
4LPJ0162GDNL Made in China Price
4. LED optional, EMI-finger Optional.

1X1  RJ45 Magjack with/without leds, meeting IEEE 802.3af/at
Single Port RJ45 Modular Jack with 10/100 Base-T Integrated Magnetics,Yellow/Green LED,Tab Down,RoHS
LINK-PP Part Number LPJ0162GDNL
Hanrun Part Number HR871156C
Application-Lan ETHERNET(NoN PoE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port 4
Diodes NO DIODES
LED Option YELLOW/GREEN
Latch TAB DOWN
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.531
Package Height (mm) 13.50
Package Length (Inches) 0.839
Package Length (mm) 21.30
Package Width (Inches) 0.626
Package Width (mm) 15.90
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Speed 10/100 BASE-T
Temperature 0 TO 70℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT

HR871155C Single Port RJ45 Modular Jack with 10/100 Base-T LPJ0162GDNL 0

Applications For Terminal User

Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways setup,Border Gateway Protocol,fast ethernet switch ...

Competitive Advantage

18 years production experience,
2600 staff,
100% test
Flexible delivery time

Main Customer

Design for Ti , Intel , Samsung ,  Fluke , Jabil  , Flextronics ,Cypress, Freescale.......
