RJHSE5085 Unshielded THT RJ45 Female Connector Single Port LPJE101NWNL

Product Details

Place of Origin: China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: RJHSE5085

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000/25K

Price: $0.09-$1.85

Packaging Details: 50PCS/tray;1200PCS/carton

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 4000K/month

Get Best Price
Highlight:

rj45 smd connector

,

shielded rj45 plugs

Specification:
RJHSE5085
Cross Part NO:
LPJE101NWNL
Mounting:
Thru-hole R/A
Samples:
Available 2-3 Pcs
Latch:
Tab Down
Files:
PDF/3D/ISG/Stp/Step/Datasheet
Specification:
RJHSE5085
Cross Part NO:
LPJE101NWNL
Mounting:
Thru-hole R/A
Samples:
Available 2-3 Pcs
Latch:
Tab Down
Files:
PDF/3D/ISG/Stp/Step/Datasheet
RJHSE5085 Unshielded THT RJ45 Female Connector Single Port LPJE101NWNL
RJHSE5085 Unshielded THT RJ45 Female Connector Single Port LPJE101NWNL



Unshielded THT RJ45 Female Connector ,Green/Green LED,Tab Up,RoHS
LINK-PP Part Number LPJE101NWNL
Amphenol Part Number RJHSE5085
Application-Lan ETHERNET
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port NON
Diodes NO DIODES
LED Option Green/Green
Latch TAB UP
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.491
Package Height (mm) 12.48
Package Length (Inches) 0.594
Package Length (mm) 15.08
Package Width (Inches) 0.620
Package Width (mm) 15.76
Pin Type THT
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITHOUT
Speed -
Temperature -40 TO +85℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT

Why Choose Us

World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers



100% Guarantee Qualtiy

•Manufactured Under Strict Controls.

•100% Tested (Not Just Batch Tested)

•LINK-PP Is OEM Of TE (Tyco) For 9 Years

•Successful Customer: Texas Instruments Samsung Cisco Siemens And Intel…

•LINK-PP Is The Preferred Supplier Of TI (Texas Instruments)

•Quality Guarantee:6 Years



5288-B*10 1 Port Unshielded RJ11 4P4C Connector without Magnetics LPJE8015NNL
