SMT Magnetic Discrete Toroidal 1000Base-T Transformer G24102DU

China SMT Magnetic Discrete Toroidal 1000Base-T Transformer G24102DU supplier
SMT Magnetic Discrete Toroidal 1000Base-T Transformer G24102DU supplier SMT Magnetic Discrete Toroidal 1000Base-T Transformer G24102DU supplier

Large Image :  SMT Magnetic Discrete Toroidal 1000Base-T Transformer G24102DU

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,Reach,SGS,RoHS
Model Number: G24102DU

Payment & Shipping Terms:

Minimum Order Quantity: 500pcs
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000K/month
Contact Now
Detailed Product Description
PN#: G24102DU Made In China: SM-LP82459PNL
Interface: Gigabyte Lan Samples: Available

SMT Magnetic Discrete Toroidal 1000Base-T Transformer G24102DU

Electrical Specifications @25℃
1.Turns Ratio(%%P5%): 1CT∶1
2.OCL: 350uH Min
  @100KHz,100mV,8mA DC BIAS
3.Insertion Loss:
  1-100MHz:-1.1 dB MAX
4.Return Loss(dB MIN):
  30MHz:-18        60-80MHz:-12
  100MHz:-10
5.Crosstalk(dB MIN):
  30MHz:-40        60MHz:-35
  100MHz:-30
6.Common Mode Rejection Ratio(dB MIN):
  30MHz:-40        60MHz:-35
  100MHz:-30
7.Hipot: 1500Vrms
8.Operating Temperature: 0℃~70℃.

SMT Magnetic Discrete Toroidal 1000Base-T Transformer G24102DU

10/100/1000 Base -T Single Port Transformer Magnetic Modules ,THT,Rohs
LINK-PP Part Number: LP82459PNL
Other Part Number: G24102DU
Speed: 10/100/1000 BASE-T
Application - LAN: ETHERNET (NoN PoE)
Package: THT
Temperature: 0 TO + 70℃
AutomDX: YES
Comment: SAME AS NL VERSION
Configuration RX: T,C,S
Configuration TX: T,C,S
Construction: OPEN FRAME
Cores Per Port: 8
Number of Ports: Single Port
Package Height (Inches): 0.472
Package Height (mm): 12.00
Package Length (Inches): 0.610
Package Length (mm): 15.5
Package Width (Inches): 0.433
Package Width (mm): 11.00
Turns Ratio RX: 1CT:1CT
Turns Ratio TX: 1CT:1CT
