Model: H1197NL Category: Transformers Audio & Signal
Frequency Range: 1 MHz To 100 MHz Application: Power Over Ethernet Magnetic Modules
Termination Style: SMD/SMT Solation Voltage:: 1.5KV
Archivi Disponibili: PDF/3D/ISG/Stp/Step/Datasheet

XFRM SIN 100D 1:1 SMT  H1197NL Transformers Power over Ethernet Magnetic Modules

XFRM 1:1 SMT H1197NL Transformers H1197NLDatasheet/Price/Cross H1197NL Specifications



LP1197NL  Equivalent Part / Cross Compatible Specification



Electrical Specifications @25℃


1.Insertion Loss:
  1-100MHz:-1.2dB Max
2.Return Loss:
  1-30MHz:-16dB Min
  40MHz:-14dB Min
  50MHz:-13dB Min
  60-80MHz:-12dB Min
3.Crosstalk:
  30MHz:-45dB Min
  60MHz:-40dB Min
  100MHz:-35dB Min
4.Differential to Common Mode Rejection:
  30MHz:-43dB Min
  60MHz:-37dB Min
  100Mhz:-33dB Min
5.Isolation Voltage:1500Vrms
6.Operating Temperature: -40℃~+85℃.



 NOTES:



Lan Magnetics Transformer  / Lan transformer sheet
Lan Discrete Transformer Modules / Lan transformer we Rj45Lan 10/100 baset
transformer ethernet / Lan transformers

Designed to support application,such as SOHO(ADSL modems),LAN-on-Motherboard(LOM),hub and Switches.
With various Turns Ratios.
RoHS"NL" peak solder rating 245℃.
