749020010A Gigabit Ethernet Transformer LAN-Übertrager WE - LAN SMD 1500Vrms

China 749020010A Gigabit  Ethernet Transformer LAN-Übertrager WE - LAN SMD 1500Vrms supplier
749020010A Gigabit  Ethernet Transformer LAN-Übertrager WE - LAN SMD 1500Vrms supplier 749020010A Gigabit  Ethernet Transformer LAN-Übertrager WE - LAN SMD 1500Vrms supplier

Large Image :  749020010A Gigabit Ethernet Transformer LAN-Übertrager WE - LAN SMD 1500Vrms

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,Reach,SGS,RoHS
Model Number: 749020010A

Payment & Shipping Terms:

Minimum Order Quantity: 1600
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock or 3 weeks
Payment Terms: T/T, Western Union
Supply Ability: 3000K/month
Contact Now
Detailed Product Description
Specifications: 749020010A Transformer Type: Isolation And Data Interface
Turns Ratio - Primary:Secondary: 1 : 1 Transmitter, 1 : 1 Receiver Mounting Type: Surface Mount
Size / Dimension: 13.97mm L X16.51mm W Height - Seated (Max): 6.25 Mm
Archivi Disponibil: PDF/3D/ISG/Stp/Step/Datasheet

749020010A Gigabit Ethernet Transformer LAN-Übertrager WE-LAN 1CT:1CT SMD 1500Vrms

Product Features
1.ULTRA ™ , E-ULTRA ™ , and ULTRA-II ™
2.IEEE802.3u Compliant
3.UL/EN60950 Recognized
4.100% Compliance Testing
5.1500Vrms Hi-Pot
6.Patented Open Frame Construction
7.Design Part Number: 749020010A
8.Mass Production Part Number : LP5004NL

Electrical Specifications (25)



749020010A Gigabit Transformer LAN-Übertrager WE-LAN 1CT:1CT SMD 1500Vrms
1. Turns Ratio50KHz, 0.5V
    Chip side: Line side=1CT: 1CT+_2%
2. Inductance (Ls) 100KHz, 0.1V, 12mA DC Bias:
    Chip side: 350uH Min
3. Insertion Loss1-100MHz: -1.4dB Max
4. Return Loss1-30MHz: -16dB Min
            40MHz: -14.4dB Min
            50MHz: -13.1dB Min
            60-80MHz: -12dB Min
            100MHz: -10dB Min
5. Differential to Common Mode Rejection:
            30MHz: -45dB Min
            60MHz: -40dB Min
            100MHz: -35dB Min
6. Crosstalk30MHz: -40dB Min
             60MHz: -35dB Min
             100MHz: -30dB Min
7. Hi-Pot: 1500Vrms, 0.5mA, 1Sec
    Chip side to Line side

Applications For Terminal User

Designed to support applications, such as ADSL modems, LAN-on-Motherboard. Networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways setup,Border Gateway Protocol,fast ethernet switch ...



SPECIFICATIONS
Mfr Package Description ROHS COMPLIANT
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Transformer Type DATACOM TRANSFORMER
Application LAN; 1000 BASE-T
Approvals UL
Insertion Loss 1.0 dB
Isolation Voltage 1500.0 V
Manufacturer Series 749020010A
Mounting Feature SURFACE MOUNT
Number of Functions 4
Operating Temperature-Min -40.0 Cel
Operating Temperature-Max 85.0 Cel
Packing Method TAPE & REEL
Physical Dimension L17.5XB14.20XH6.50 (mm)
Primary Inductance 350.0 µH
Sub Category Other Transformers
Turns Ratio (Np:Ns) 1:1; 1:1
Height 6.5 mm
Length 17.5 mm
Width 14.2 mm
Additional Feature HEIGHT DIMENSION INCLUDES TERMINALS ALSO



Other Replaceable List



TD11-6006G
TD37-1205ALF
TG42-1205NM5RL
TG42-1205NSRL
TD12-0756F
TD38-1505ALF
TG49-1205NM5RL
TG70-1205NSRL
TD12-0756G
TD70-1205ALF
TG83-1205NM5RL
TG71-1205NSRL
TD12-1506F
TD71-1205ALF
TGSP-S125NM5RL
TG08-1205N1LF
TD12-1506G
TD72-1205ALF
TG36-1505NZRL
TG24-1205N1LF
TD12-2506F
TG02-1205NSRL
TG43-1505NZRL
TG26-1205N1LF
TD12-2506G
TG04-1205NSRL
TG48-1505NZRL
TG27-1205N1LF
TG110-RP01NZRL
TG08-1205NSRL
TG75-1505NZRL
TG38-1205N1LF
TG110-RP03NZRL
TG10-1205NSRL
TG85-1505NZRL
TG42-1205N1LF
TG110-RPE9NZRL
TG15-1205NSRL
TG85-S002NZRL
TG48-1205N1LF
TG110-RP05NYRL
TG23-1505NSRL
TG93-1505NZRL
TG63-1205N1LF
TG110-RP10NYRL
TG37-1205NSRL
TG96-1505NZRL
TG64-1205N1LF
TG110-RPE10NYRL
TG38-1205NSRL
TG97-1505NZRL
TG73-1205N1LF
TG08-1505N5LF
TG23-1505NZRL
TG98-1505NZRL
TG74-1205N1LF
TG23-1505N5LF
TG24-1505NZRL
TGSP-S225NZRL
TG80-1205N1LF
TG24-1505N5LF
TG26-1505NZRL
TGSP-S281NZRL
TG27-1505N5LF
TG26-1505N5LF
TG27-S004NZRL
TG08-1505NZRL
TG38-1505N5LF
