Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: G24102MK
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Part Number: |
G24102MK |
Transformer Type: |
Isolation And Data Interface |
Turns Ratio - Primary:Secondary: |
1 : 1 Transmitter, 1 : 1 Receiver |
Mounting Type: |
Surface Mount |
Size / Dimension: |
13.97mm L X16.51mm W |
Height - Seated (Max): |
6.25 Mm |
Part Number: |
G24102MK |
Transformer Type: |
Isolation And Data Interface |
Turns Ratio - Primary:Secondary: |
1 : 1 Transmitter, 1 : 1 Receiver |
Mounting Type: |
Surface Mount |
Size / Dimension: |
13.97mm L X16.51mm W |
Height - Seated (Max): |
6.25 Mm |
1.Design For Long Hual Gigabit Ethernet 100/1000 BASE-Tx Full Duplex Applications.
2.Low Profile Surface Mount Packaging Designed Reflow Process ( 250°C peak ).
3.Compliant With IEEE 802ab draft standards for 1000Base-T.
4.Supports 4 Pairs Of Category 5 UTP Cable.
5.For RoHS Part Add Suffix G.
6.Design Part Number: 【G24102MK】
7.Mass Production Part Number 【LP5004NL】
G2405CG Gigabit Transformer Surface Mount Type 1CT:1CT SMD 1500Vrms Open Header
1. Turns Ratio50KHz, 0.5V
Chip side: Line side=1CT: 1CT+_2%
2. Inductance (Ls) 100KHz, 0.1V, 12mA DC Bias:
Chip side: 350uH Min
3. Insertion Loss1-100MHz: -1.4dB Max
4. Return Loss1-30MHz: -16dB Min
40MHz: -14.4dB Min
50MHz: -13.1dB Min
60-80MHz: -12dB Min
100MHz: -10dB Min
5. Differential to Common Mode Rejection:
30MHz: -45dB Min
60MHz: -40dB Min
100MHz: -35dB Min
6. Crosstalk30MHz: -40dB Min
60MHz: -35dB Min
100MHz: -30dB Min
7. Hi-Pot: 1500Vrms, 0.5mA, 1Sec
Chip side to Line side
Designed to support applications, such as ADSL modems, LAN-on-Motherboard. Networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways setup,Border Gateway Protocol,fast ethernet switch ...
18 years production experience,
2600 staff,
100% test
Flexible delivery time
Design for Ti , Intel , Samsung , Fluke , Jabil , Flextronics ,Cypress, Freescale,EKF.......
Built-in Flexible PCB Assembly; Rigid-Flexible PCB Assembly; Microelectronic, Flip Chip; Microelectronic, Chip On Board; Optoelectronic Assembly; RF / Wireless Assembly; Through Hole Assembly; Surface Mount Assembly; System Assembly; Printed Circuit Board Assembly
