RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL

China RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL supplier
RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL supplier RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL supplier RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL supplier

Large Image :  RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL

Product Details:

Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH
Model Number: RJPS-001TC1

Payment & Shipping Terms:

Minimum Order Quantity: 770 PCS
Price: Supported & Discount
Packaging Details: 110PCS/Reel,7Reels/Carton,770PCS=10KG=35.5*35.5*35cm
Delivery Time: Stock or 4 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000000/Month
Contact Now
Detailed Product Description
Specification: RJPS-001TC1 Part Number: LPJ19960CNL
Munafactuer: LINK-PP Ethernet: 10/100Mbps Ethernet
Mounting: SMD Samples: Free

RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL



  • Low Profile RJ45 connector-jack
  • Power Over Ethernet Rj45 Magnetics Module
  • RJPS-001TC1 Surface Mounting Mod Jack
  • 1 x 10/100 Mbit Ethernet
  • Lan connector Rj45 LPJ19960CNL
  • Lan Connectors Rj45 Without Led


Features:
◎ RoHS Compliant
◎ Do not use material and use that the prohibition that SS-00259 stipulates
◎ Fully shielded magnetics protect data from internally generated digital noise
◎ Reduces the overall length of the signal path for improved common mode performance
◎ Implements full common mode termination scheme with used and unused
    twisted pairs
◎ Meets IEEE802.3 Baseline Wander Compensation specification
◎ Integrates high voltage capacitor to chassis ground
◎ Supports all major transceivers with matched turns ration and complete integration of specified termination
◎ Design for 100base-tx transmission over UTP-5 cable
◎ Operating TEMP. range: -40 to +85 ℃ ℃
◎ Storage TEMP. range: -55 to + 125 ℃ ℃ ℃
◎ Primary OCL inductance: 350μH MIN. at 100KHz/0.1Vrms with 8mA DC bias



SMT Rj45 Power Over Ethernet IEEE802.3af
RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL
RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL RJPS-001TC1 SMD POE Rj45, Low Profile,1x 10/100 Base-TX Filtered LPJ19960CNL
