Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: FTGL2025S1TUS
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Specifications: |
FTGL2025S1TUS |
Data Rate: |
2488.32Mbps |
Wavelength: |
1490nm |
Maximun Distance: |
- |
Fiber Type: |
Singlemode Glass |
Emitter: |
FP Laser |
Voltage: |
3.3V |
Applications: |
General Purpose |
Connector: |
SC |
Mounting: |
Pluggable,SFP |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1 (Unlimited) |
Specifications: |
FTGL2025S1TUS |
Data Rate: |
2488.32Mbps |
Wavelength: |
1490nm |
Maximun Distance: |
- |
Fiber Type: |
Singlemode Glass |
Emitter: |
FP Laser |
Voltage: |
3.3V |
Applications: |
General Purpose |
Connector: |
SC |
Mounting: |
Pluggable,SFP |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1 (Unlimited) |
| Specifications: | FTGL2025S1TUS |
| LINK-PP Part Number: | LPXXXXXX |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | SFF |
| Product Name: | SFF Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
2488.32Mbps |
| Wavelength: | 1490nm |
| Maximun Distance: | - |
| Fiber Type: | Singlemode Glass |
| Emitter: | FP Laser |
| Voltage-Supply: | 3.3V |
| Applications: | General Purpose |
| Connector Type: | SC |
| Mounting Type: | Pluggable,SFP |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 1 (Unlimited) |
|
Feature Description:
|
● Bi-directional transceivers operating at 2.488 Gbit/s downstream, 1.244 Gbit/s upstream
● Di-plexer operation at 1490 nm Tx, and 1310 nm digital Rx
● Burst-mode APD receiver
● Continuous mode transmitter with DFB laser
● Built-in digital diagnostic functions
● Standard small form-factor (SFF) package with fiber pigtailed SC/UPC connector in compliant with GR326 and UL 94V0 flammability
● The pigtail comes in a tight buffer 0.9mm, 9/125/250 SMF-28 or equivalent
● Single 3.3V power supply
● Industrial operating temperature range: -40℃ to 85℃
