FTEN2217P1CUN 1.25GB Fiber Optic Transceiver Module General Data Transfer

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: ISO 9001,ISO 14001,UL,SGS,REACH168

Model Number: FTEN2217P1CUN

Payment & Shipping Terms

Minimum Order Quantity: 10/100/25K

Price: $0.11-$35

Packaging Details: 20/Tray

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 350K/Month

Get Best Price
Highlight:

sfp optical module

,

fiber optic transceiver

Specifications:
FTEN2217P1CUN
Data Rate:
1250Mbps
Wavelength:
1310nm
Brand:
LINK-PP
Fiber Type:
Singlemode Glass
Emitter:
EML
Voltage:
3.15V~3.45V
Applications:
General Data Transfer
Connector:
SMF SC
Mounting:
Pluggable,SFP
CE RoH:
Compliant
Temperature Range:
0 ~ 70℃
Specifications:
FTEN2217P1CUN
Data Rate:
1250Mbps
Wavelength:
1310nm
Brand:
LINK-PP
Fiber Type:
Singlemode Glass
Emitter:
EML
Voltage:
3.15V~3.45V
Applications:
General Data Transfer
Connector:
SMF SC
Mounting:
Pluggable,SFP
CE RoH:
Compliant
Temperature Range:
0 ~ 70℃
FTEN2217P1CUN 1.25GB Fiber Optic Transceiver Module General Data Transfer

FTEN2217P1NUN | 1.25GB Fiber Optic Transceiver Module General Data Transfer

Specifications: FTEN2217P1CUN
LINK-PP Part Number: LPXXXXXX
Product Class: Fiber Optics
Product Family: Optical Transceivers
Product Series: SFP
Product Name: SFP Optical Transceivers
Status Available: Active
RoHS: RoHS-6 Compliance



Specifications:



Data Rate:



1250 Mbps

Wavelength: 1310nm
Maximun Distance: 10000m
Fiber Type: Singlemode Glass
Emitter: EML
Voltage-Supply: 3.15V~3.45V
Applications: General Data Transfer
Connector Type: SC
Mounting Type: Pluggable,SFP
Lead Free Status / RoHS Status: Lead Free / RoHS Compliant
Moisture Sensitivity Level(MSL): 1(Unlimited)



Feature Description:



● EPON ONU in MSA SFP Footprint
● Compliance with IEEE802.3ah1
● Optional CTC OAM Support, or DPoETM Support
● Built-in Digital Diagnostics Functions
● Single fiber Bi-Directional SC Receptacle
● Compatibility with EPON OLTs and CPE Equipment



Description:



● EPON Stick (SFP-ONU) provides a unique enhanced digital diagnostic monitoring interface which allows real-time access to a device’s operating parameters such as transceiver temperature, laser bias current, transmitted optical power,received optical power and transceiver supply voltage. It also defines a sophisticated system of alarms and warning flags which alerts end-users when certain operating
parameters are outside of a factory-set normal range.
● The SFP MSA defines a 256-byte memory map in EEPROM that is accessible over a 2-wire serial interface at the 8 bit address 1010000X (A0h). The digital diagnostic monitoring interface makes use of the 8 bit address 1010001X (A2h), A0h stores static information including product and vendor IDs while A2h contains real-time diagnostic data.



Applications:



● Providing Pluggable EPON ONU
● Interface for Ethernet Switches
● Wireless Backhaul Equipment
● Ethernet Demarcs

● Routers
● DSLAMs and other Customer Premises Equipment
