TG1G-S220NWLF SMD 50 Pin Slimline Dual Port Gigabit Isolation Modules

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: UL,RoHS,Reach,ISO

Model Number: TG1G-S220NWLF

Payment & Shipping Terms

Minimum Order Quantity: 400/2000/10K/25K

Price: $0.06-$3.2

Packaging Details: T&R

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 3KK/Month

Get Best Price
Highlight:

100/1000base-t filter

,

100base-t transformer

Specs:
TG1G-S220NWLF
Cross:
LP5020NLR
Pin No:
50pins
Series:
Dual Port GigE Transformer
Termination Style:
SMD/SMT
Isolation Voltage::
1.5KV
Samples:
Free Offer
Specs:
TG1G-S220NWLF
Cross:
LP5020NLR
Pin No:
50pins
Series:
Dual Port GigE Transformer
Termination Style:
SMD/SMT
Isolation Voltage::
1.5KV
Samples:
Free Offer
TG1G-S220NWLF SMD 50 Pin Slimline Dual Port Gigabit Isolation Modules
TG1G-S220NWLF SMD 50 Pin Slimline Dual Port Gigabit Isolation Modules



  • Product Features:
  • Dual Port Gigabit Ethernet Transformer/Choke
  • Slimline Package Design
  • IEEE802.3ab Compliant
  • UL/EN60950 Recognized
  • 100% Electrical Testing
  • 1500Vrms Hi-Pot
  • Patented Open Frame Construction
  • TG1G-S220NWLF Compatible / Cross / Pin to Pin
  • Dual Port GigE Transformer



Electrical Specifications @25℃


1.Insertion Loss:
  1-100MHz:-1.2dB Max
2.Return Loss:
  1-30MHz:-16dB Min
  40MHz:-14dB Min
  50MHz:-13dB Min
  60-80MHz:-12dB Min
3.Crosstalk:
  30MHz:-45dB Min
  60MHz:-40dB Min
  100MHz:-35dB Min
4.Differential to Common Mode Rejection:
  30MHz:-43dB Min
  60MHz:-37dB Min
  100Mhz:-33dB Min
5.Isolation Voltage:1500Vrms
6.Operating Temperature: 0℃~+70℃.
