Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics

Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics

Product Details

Place of Origin: GuangDong, China

Brand Name: LINK-PP

Certification: ISO9001,SGS,UL,CE,REACH163

Model Number: JG0-0027NL

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000/25K

Price: $0.11-$12

Packaging Details: Tray

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 208K/Month

Get Best Price

Product Details

Product Description
Highlight:

multi port connector

,

dual rj45 jack

Designe PN#:
JG0-0027NL
Made In China:
LPJG68851AWNL
Category:
Cat5/6
Interface:
10/100/1000Mbps
LED:
G-G
Samples:
Available
Designe PN#:
JG0-0027NL
Made In China:
LPJG68851AWNL
Category:
Cat5/6
Interface:
10/100/1000Mbps
LED:
G-G
Samples:
Available
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics

Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics



PulseJack JG0-0027NL
Trader Part Number
JG0-0027NL
Price Break
Unit Price
Extended Price
1-5
A
-
10-50
B
-
100-500
C-1
-
1,000-2,500
Supportive
-
5,000
Dynamic
Dynamic
10,000
Dynamic
Dynamic
50,000
 Negotiable
Negotiable
100,000
 Negotiable
Negotiable
500,000
 Negotiable
Negotiable
Made in China
LPJG68851AWNL
Manufacturer
LINK-PP China
Description
 Multi 6 Ports
Documents Available
PDF/3D/Step/IGS/Price/Cross
Quantity Available
200,000 PCS or 4 weeks



10/100/1000 Base-T RJ45 1xN Tab-UP Integrated Connector Module (ICM) with or without LEDs

JG0-0027NL ELECTRICAL SPECFICATIONS @25℃
1.Turns Ratio:
  TX = 1CT:1CT      RX = 1CT:1CT
2.OCL(100KHz,0.1V,8mA DC BIAS):
  350uH MIN
3.Insertion Loss:
  1～100MHz:-1.5dB MAX
4.Return Loss(@100Ω±15%):
  2～30MHz:-16dB MIN
  60～80MHz:-10dB MIN
5.Crosstalk:
  0.1～100MHz:-30dB MIN
6.Hipot Test: 1500Vrms MIN
7.Operating Temperature: -40℃ TO +85℃.
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics 0Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics 1
Pulse JG0-0027NL 1x6 Tab-UP 10-pin RJ45 With Internal Magnetics 2
