LPJK7041A98NL Height 11.3mm Low-Profile Gigabit Rj45 LED Shield R/A THT

China LPJK7041A98NL Height 11.3mm Low-Profile Gigabit Rj45 LED Shield R/A THT supplier
LPJK7041A98NL Height 11.3mm Low-Profile Gigabit Rj45 LED Shield R/A THT supplier LPJK7041A98NL Height 11.3mm Low-Profile Gigabit Rj45 LED Shield R/A THT supplier

Large Image :  LPJK7041A98NL Height 11.3mm Low-Profile Gigabit Rj45 LED Shield R/A THT

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: LPJK7041A98NL

Payment & Shipping Terms:

Minimum Order Quantity: 200/500/1200
Price: Supportive
Packaging Details: 60pcs/tray,or Reel Package
Delivery Time: Stock or 4-5 weeks
Payment Terms: TT,Paypa,West Union
Supply Ability: 2800K-PCS/Month
Contact Now
Detailed Product Description
Part Number: LPJK7041A98NL Speed: 1000 Base-T
LED: Orange&Green/Yellow Core: 8
Sample: Free File: PDF/3D/ISG/Stp/Step/Datasheet

LPJK7041A98NL Height 11.3mm Low-Profile Gigabit Rj45 LED Shield R/A THT
  1. LPJK7041A98NL LINK-PP Small Rj45
  2. Compatible to L829-1J1T-DD
  3. Low Profile Rj45 10/100/1000 With Magnetics
  4. Height 11.3mm Rj45 Low Profile

LPJK7041A98NL Height 11.3mm Low-Profile Gigabit Rj45 LED Shield R/A THT

1. Product Type Features:

  1) Product Type = Connector
  2) Jack Type = RJ45
  3) Profile = Standard
  4) PCB Mounting Orientation = Side Entry (Right Angle)

2. Mechanical Attachment:
  1) Jack Configuration = 1 x 1

3. Electrical Characteristics:
  1) Shielded = Yes

4. Termination Related Features:
  1) EMI Finger - Bottom = Without
  2) Termination Method = Solder

5. Body Related Features:
  1) Port Configuration = Single/Multi
  2) EMI Fingers -Top and Sides = With/ Without
  3) Latch Orientation = Standard - Latch Down
  4) PCB Tail Length

6. Contact Related Features:
  1) Preloaded = Yes
  2) Contact Termination Type = Through Hole/Surface Mount

7. Housing Related Features:
  1) Connector Style = Jack

8. Industry Standards:
  1) RoHS/ELV Compliance = RoHS compliant, ELV compliant
  2) Lead Free Solder Processes = Wave solder capable to 240°C,

      Wave solder capable to 260°C, Wave solder capable to 265°C
  3) RoHS/ELV Compliance History = Always was RoHS compliant

9. Identification Marking:
  1) Left LED Color (Position #1) = Green - 250 ohm resistor
  2) Right LED Color (Position #2) = Green - 250 ohm resistor

10. Conditions for Usage:
  1) Applies To = Printed Circuit Board
  2) Environmental Conditions = Office / Premises
  3) Operating Temperature (°C ) = 0 - 70/-40 - +85
