Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: 615008148521
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.16
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: in Stock Ship Today
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4200K-PCS/Month
Part Number: |
615008148521 |
Cross: |
LPJE8015NNL |
Product Type: |
WR-MJ Modular Jack |
Gender: |
Female |
Pin Configuration: |
8P8C |
Port ConfigurationRange - Operating: |
1x1 |
Orientation: |
Horizontal, 90° Angle (Right) |
Tab Direction: |
Up |
Mounting Type: |
Through Hole |
Shielding: |
Plastic / Unshielded |
Contact Material: |
Copper Alloy |
Contact Plating: |
Gold |
Housing Material: |
PBT |
Flammability Rating: |
UL94 V-0 |
Rated Current: |
1.5 A |
Working Voltage: |
120 V AC |
Operating Temperature: |
-40°C To +85°C |
Durability: |
500 Mating Cycles |
Part Number: |
615008148521 |
Cross: |
LPJE8015NNL |
Product Type: |
WR-MJ Modular Jack |
Gender: |
Female |
Pin Configuration: |
8P8C |
Port ConfigurationRange - Operating: |
1x1 |
Orientation: |
Horizontal, 90° Angle (Right) |
Tab Direction: |
Up |
Mounting Type: |
Through Hole |
Shielding: |
Plastic / Unshielded |
Contact Material: |
Copper Alloy |
Contact Plating: |
Gold |
Housing Material: |
PBT |
Flammability Rating: |
UL94 V-0 |
Rated Current: |
1.5 A |
Working Voltage: |
120 V AC |
Operating Temperature: |
-40°C To +85°C |
Durability: |
500 Mating Cycles |
Explore the 615008148521 WR-MJ Modular Jack Tab Up, a 1x1 8P8C RJ45 through hole right angle connector with UL94 V-0 PBT housing, gold-plated copper alloy contacts, and CAT 3 application support.
The 615008148521 WR-MJ Modular Jack Tab Up is a compact 8P8C RJ45 modular jack designed for reliable Ethernet and communication applications. Featuring a 1x1 port layout, horizontal right-angle orientation, and tab-up configuration, this connector is built for stable board-level integration in space-conscious network hardware and industrial communication systems.
With a through hole termination, gold-plated copper alloy contacts, and a PBT housing rated UL94 V-0, the 615008148521 offers dependable electrical performance, mechanical durability, and consistent signal integrity. It is well suited for CAT 3 applications, as well as systems requiring a robust unshielded modular jack solution.
The 615008148521 WR-MJ Modular Jack Tab Up supports important industry compliance requirements:
These certifications help support procurement requirements for regulated markets and professional electronics manufacturing.
| Parameter | Value |
|---|---|
| Rated Current | 1.5 A |
| Working Voltage | 120 V AC |
| Withstanding Voltage | 1000 V AC for 1 minute |
| Contact Resistance | 20 mΩ max. |
| Insulation Resistance | 500 MΩ min. |
| Parameter | Value |
|---|---|
| Number of Positions/Contacts | 8P8C |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Shielding | Unshielded |
| Tab Direction | Up |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Housing Color | Black |
| LED | No LED |
| Durability | 500 mating cycles |
It is an 8P8C RJ45 modular jack with a horizontal right-angle, tab-up design, used in networking and communication equipment.
No. This model is listed as unshielded / plastic shielding.
The connector uses a through hole mounting style with solder termination.
The operating temperature range is -40°C to +85°C.
Yes. As an 8P8C RJ45 modular jack, it is suitable for Ethernet-related connectivity and CAT 3 application environments.
Plese Email Us for RJ45 Connector Datasheet
|
