Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: HR915340A
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.05-$1.28
Packaging Details: Tray Package: Carton size 32*30*31cm , G.W/carton 8.5kg , Qty/carton 1200pcs , SPQ 50pcs
Delivery Time: in Stock Ship Today
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 6000K/month
Part Number: |
HR915340A |
Shielding: |
Shielded |
Magnetics: |
100 Base-T |
LED Color: |
Green/Yellow |
Mounting Type: |
Through Hole |
Cross Ref: |
LPJ16211BENL |
Isolation Voltage: |
2250VD |
OCL: |
350µH |
Part Number: |
HR915340A |
Shielding: |
Shielded |
Magnetics: |
100 Base-T |
LED Color: |
Green/Yellow |
Mounting Type: |
Through Hole |
Cross Ref: |
LPJ16211BENL |
Isolation Voltage: |
2250VD |
OCL: |
350µH |
The HR915340A is a single-port RJ45 connector with integrated magnetics, designed for 10/100Base-T Ethernet applications. It combines the Ethernet transformer, RJ45 jack, shielding, and LED indicators into a single compact unit. This reduces board space, simplifies PCB layout, and enhances signal integrity.
| Parameter | Specification |
|---|---|
| RoHS | Compliant (Pb Free) |
| Isolation Voltage | 2250 VDC, 0.5 mA, 60 sec (UTP side to chip side) |
| OCL (Open Circuit Inductance) | 350 µH minimum @100 kHz, 100 mV with 8 mA DC |
| Insertion Loss | ≤ –1.0 dB (300 kHz ~ 100 MHz) |
| Return Loss | ≤ –20 dB (1 MHz ~ 10 MHz) ≤ –16 dB (10 MHz ~ 30 MHz) ≤ –12 dB (30 MHz ~ 60 MHz) ≤ –10 dB (60 MHz ~ 80 MHz) |
| Common Mode Rejection (CMR) | ≥ –30 dB (1 MHz ~ 50 MHz) ≥ –20 dB (50 MHz ~ 150 MHz) |
| Crosstalk | ≤ –40 dB (1 MHz ~ 30 MHz) ≤ –35 dB (30 MHz ~ 60 MHz) ≤ –30 dB (60 MHz ~ 100 MHz) |
The HR915340A is widely used in networking and communication equipment, including:
