JD0-0001NL 1x1 Gigabit RJ45 Connector with Magnetics and LEDs

The JD0-0001NL is a premium 1x1 Gigabit Ethernet RJ45 magnetic jack designed for robust and reliable network connectivity. Supporting 1000BASE-T speeds, this through-hole (THT) side-entry connector features integrated magnetics, advanced EMI shielding, and built-in Green/Yellow LEDs for status indication. With a high isolation voltage of 2250VDC and compliance with FCC Part 68, it is an ideal solution for networking equipment, industrial PCs, routers, and switches requiring uncompromised signal integrity.

Key Features of JD0-0001NL PulseJack

1. High-Speed Gigabit: Optimized for 1000BASE-T Ethernet applications.
2. Integrated Magnetics: Minimizes PCB footprint and ensures excellent signal integrity (350µH min OCL @ 8mA DC bias).
3. Robust Isolation: 2250VDC Hi-Pot isolation (PHY side to Line side) for superior equipment protection.
4. Durable Construction: UL94 V-0 flame-retardant housing with a fully shielded brass/nickel enclosure.
5. Gold-Plated Contacts: 6µ-inch selective gold plating ensures reliable mating and long-term durability.
6. Wave Solder Compatible: Designed to withstand peak soldering temperatures up to 260°C (10 seconds max).

Technical Specifications of JD0-0001NL Gigabit RJ45 Magjack

Electrical Performance of JD0-0001NL RJ45 Connector with LED

The JD0-0001NL is engineered for reliable Ethernet signal performance in 1000BASE-T networks.

LED Specifications

Test condition: Forward current 20 mA

The dual-LED design supports clear port status indication for link and activity monitoring.

JD0-0001NL Datasheet

Material Specifications of JD0-0001NL 1000BASE-T RJ45 Connector

• Housing: Thermoplastic, Black, UL94 V-0 rated
• Shield Material: Brass with Nickel Plating
• Contact Material: Phosphor Bronze
• Contact Plating: Selective Gold, 6µ-inch Minimum in mating/contact area

JD0-0001NL Price

FAQ About JD0-0001NL RJ45 with Magnetics

If your design requires a compact 1x1 RJ45 connector with gigabit Ethernet support, integrated magnetics, and reliable THT mounting, the JD0-0001NL offers a practical balance of electrical performance, mechanical stability, and assembly efficiency. Its non-PoE structure, side-entry layout, and LED indicators make it especially suitable for standard network products where clean board integration and dependable operation matter.

1. What is the JD0-0001NL used for?

The JD0-0001NL is used in 1000BASE-T Ethernet applications such as switches, routers, embedded networking devices, and industrial communication systems.

2. Does the JD0-0001NL support PoE?

No. The JD0-0001NL is a non-PoE RJ45 connector.

3. What type of mounting does this connector use?

It uses a through-hole (THT) package with a side-entry PCB mount angle.

4. Does it include LED indicators?

Yes. It supports green and yellow LED options for port status indication.

5. What is the operating temperature range?

The operating temperature range is 0°C to +70°C.
