Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH
Model Number: LX-SM31TG-40DC
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Specifications: |
LX-SM31TG-40DC |
Data Rate: |
8.0Gb/s To 11.1Gb/s Bit Rates |
Standard: |
SONET OC-192&SDH STM-64 At 9.953Gbps |
Connector Type: |
Hot-pluggable XFP Footprint |
Distance: |
40km With SMF |
Voltage: |
+3.3V |
Environment: |
Lead Free / RoHS Compliant |
Operation Tem: |
-40℃ To +85 ℃ |
Specifications: |
LX-SM31TG-40DC |
Data Rate: |
8.0Gb/s To 11.1Gb/s Bit Rates |
Standard: |
SONET OC-192&SDH STM-64 At 9.953Gbps |
Connector Type: |
Hot-pluggable XFP Footprint |
Distance: |
40km With SMF |
Voltage: |
+3.3V |
Environment: |
Lead Free / RoHS Compliant |
Operation Tem: |
-40℃ To +85 ℃ |
Product Features
Supports 8.0Gb/s to 11.1Gb/s bit rates
Hot-pluggable XFP footprint, Built-in digital diagnos
Maximum link length of 40km with SMF
1310nm DFB laser and PIN photodiode
XFP MSA package with duplex LC connector
No reference clock required
Single +3.3V power supply
Power dissipation <1.5W
Compatible with RoHS
Temperature range:0 to +70°C
Applications
SONET OC-192&SDH STM-64 at 9.953Gbps
10GBASE-LR/LW 10G Ethernet
1200-SM-LL-L 10G Fibre Channel
10GE over G.709 at 11.09Gbps
OC192 over FEC at 10.709Gbps
Other optical links, up to 11.1Gbps
Description
The XFP module is compliant with the 10G Small Form-Factor Pluggable (XFP) Multi-Source
Agreement (MSA), supporting data-rate of 8.0~11.1Gbps, and transmission distance up to 40km on
SMF.
The transceiver module comprises a transmitter with 1310nm DFB laser and a receiver with a PIN
photodiode. Transmitter and receiver are separate within a wide temperature range and offers optimum
heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE
systems.
