Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH
Model Number: 7498111120AR
Payment & Shipping Terms
Minimum Order Quantity: 1000/5K,20K
Price: $0.46
Packaging Details: 110pcs/Reel
Delivery Time: 3-5 days
Payment Terms: TT,NET30/60/90 Days,Western Union,D/P
Supply Ability: 100K-PCS/Month
Part Number: |
7498111120AR |
Equivalent: |
LPJG19562AGNL |
Type: |
Rj45 With Magnetic |
Mounting: |
SMT |
Data Rate: |
1000BASE-T (Gigabit Ethernet) |
Port Configuration: |
1x1 (Single Port) |
Tab Orientation: |
Tab Up |
LED Indicators: |
Yellow / Green |
Operating Temperature: |
-40 °C Up To +85 °C |
PoE Status: |
Non-PoE |
PHY Chip Mode: |
Current |
Files: |
PDF/3D/ISG/Stp/Step/Datasheet |
Part Number: |
7498111120AR |
Equivalent: |
LPJG19562AGNL |
Type: |
Rj45 With Magnetic |
Mounting: |
SMT |
Data Rate: |
1000BASE-T (Gigabit Ethernet) |
Port Configuration: |
1x1 (Single Port) |
Tab Orientation: |
Tab Up |
LED Indicators: |
Yellow / Green |
Operating Temperature: |
-40 °C Up To +85 °C |
PoE Status: |
Non-PoE |
PHY Chip Mode: |
Current |
Files: |
PDF/3D/ISG/Stp/Step/Datasheet |
The 7498111120AR SMT RJ45 Connector is a high-performance 1-port shielded RJ45 jack with integrated magnetics, designed for reliable 1000BASE-T Gigabit Ethernet communication in demanding industrial and embedded systems. Built for SMT mounting, tab-up orientation, and -40 °C to +85 °C operating environments, this connector is a strong fit for applications where long-term signal integrity, mechanical stability, and compact PCB integration are essential.
Engineered for compatibility with a wide range of Ethernet ICs and industrial network platforms, the 7498111120AR supports use in industrial Ethernet, EtherCAT, Profinet, routers, switches, IP cameras, hubs, and IoT devices. Its shielded construction, integrated LEDs, and robust electrical performance make it an ideal choice for compact networked systems that need dependable gigabit connectivity.
| Parameter | Specification |
|---|---|
| Connector Type | RJ45 jack with integrated magnetics |
| Port Count | 1 Port |
| Contact Configuration | 8P8C |
| Mounting Type | SMT / SMD |
| Orientation | Vertical, board-edge style |
| Tab Style | Tab Up |
| Shielding | Shielded |
| Shield Tabs | Yes |
| Board Height | 0.365 in / 9.26 mm |
| LED Type | Yellow/Green |
| Parameter | Specification |
|---|---|
| Ethernet Speed | 10/100/1000BASE-T |
| Standard Compliance | IEEE 802.3ab |
| AutoMDIX | Supported |
| PoE | Non-PoE |
| OCL | Min. 350 µH |
| Test Condition for OCL | 100 kHz / 100 mV with 8 mA DC bias |
| Turns Ratio | 1:1 Tx / Rx |
| CMRR | Min. -30 dB (1 MHz–30 MHz) |
| Crosstalk | Min. -37 dB (1 MHz–30 MHz) |
| Insertion Loss | Max. -1.0 dB (1–100 MHz) |
| Return Loss | Optimized across 1–100 MHz |
| Hipot Test | 2250 Vdc for 1 minute |
The 7498111120AR SMT RJ45 connector is ideal for network equipment and industrial electronics that require reliable gigabit connectivity in harsh or temperature-sensitive environments.
Common applications include:
The 7498111120AR is constructed with materials selected for durability, signal performance, and compliance.
| Component | Material / Finish |
|---|---|
| Housing | Thermoplastic, UL 94V-0 |
| Core Material | Ferrite |
| Shield | Copper alloy base with 50 µ" nickel plating |
| Contact Plating | 30 µ" gold on contact area |
| Solder Tails | 100% tin over nickel |
| Wire | UEW/Y 180°C |
The use of a shielded housing and quality contact plating helps support reliable performance and long service life.
The 7498111120AR SMT RJ45 connector is built for industrial use and supports demanding operating environments.
Tape and reel packaging makes the part convenient for high-volume manufacturing and pick-and-place assembly lines.
