Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: MIC24013-5204T-LF3
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4600K.PCS/Month
Specification: |
MIC24013-5204T-LF3 |
Type: |
LPJ0011GENL |
Latch: |
Down |
I/O: |
10/100Mbps |
Indicator: |
LED Flexible |
Samples: |
Available |
Specification: |
MIC24013-5204T-LF3 |
Type: |
LPJ0011GENL |
Latch: |
Down |
I/O: |
10/100Mbps |
Indicator: |
LED Flexible |
Samples: |
Available |
| Pin to pin MIC24013-5204T-LF3 | |
| Factory PN | LPJ0011GENL |
| Manufacturer Series | MIC24013-5204T-LF3 |
| Manufacturer | LINK-PP |
| Cross References | Equivalent to L21N001-0 |
| Series | Connector |
| L/T | Stock or 4-5 weeks |
| Documents Available | PDF/3D/ISG/Stp/Step/Datasheet |
| mode of payment | T/T, Western Union, MoneyGram |
| LED Color | GREEN/YELLOW |
| speed | 10/00 Base-T |
| Mfr Package Description | ROHS COMPLIANT |
| REACH Compliant | Yes |
| EU RoHS Compliant | Yes |
| China RoHS Compliant | Yes |
| Status | Active |
| Connector Type | Jack |
| Application | GENERAL PURPOSE |
| Isolation Voltage | 1500.0 V |
| Mounting Feature | Side Entry (Right Angle) |
| Contact Termination Type | Through Hole |
| Primary Inductance | 350 |
| Terminal Finish | TIN |
| Samples | Available 2 pcs |
| Turns Ratio (Np:Ns) | 1:1; 1:1 |
| |
| Emitting Color | λp(nm) | VF@IF=20mA | IR @VR=5V |
| Green | 565 | 1.8~2.6V | 10μA max |
| Yellow | 585 | 1.8~2.6V | 10μA max |
Applications For Terminal User
Designed to support applications, such as ADSL modems, LAN-on-Motherboard. Networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways setup,Border Gateway Protocol,fast ethernet switch ...
Main Customer
Design for Ti , Intel , Samsung , Fluke , Jabil , Flextronics ,Cypress, Freescale,EKF.......
