MCF11B2GGA4-G709 Gigabit Single Port RJ45 Connector With Single USB LPJU3936AWNL

China MCF11B2GGA4-G709 Gigabit Single Port RJ45 Connector With Single USB LPJU3936AWNL supplier

Large Image :  MCF11B2GGA4-G709 Gigabit Single Port RJ45 Connector With Single USB LPJU3936AWNL

Product Details:

Place of Origin: China
Brand Name: LINK-PP
Certification: SGS, UL,CE,ISO9001
Model Number: MCF11B2GGA4-G709

Payment & Shipping Terms:

Minimum Order Quantity: 500/5000/10000
Price: 32% Discounted
Packaging Details: Tray, Tape & Reel
Delivery Time: Stock
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000K/month
Contact Now
Detailed Product Description
PN: MCF11B2GGA4-G709 Family: RJ45 USB Connector
Ethenet: 10/100/1000Mbps + USB2.0 Cross Rf: MCF11B2GGA4-G709 = LPJU3936AWNL
LED: Green / Green PCB Mount Angle: Side Entry

MCF11B2GGA4-G709 Gigabit Single Port RJ45 Connector With Single USB LPJU3936AWNL

• Compliant with IEEE802.3ab standard
• Tab up RJ45 Jack + 1USB Combo
• High performance for maximum EMI suppression
• 350µH minimum OCL with 8mA bias current

• Support 10/100/1000 Base-T AutoMDIX application with Bi-Color LEDs
• Network Interface Cards(NIC), LAN-on-Motherboard(LOM) and PC
• Suitable CAT 3, 5e & 6 cable and UTP



MCF11B2GGA4-G709 Gigabit Single Port RJ45 Connector With Single USB LPJU3936AWNL



Part Number MCF11B2GGA4-G709
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores Per Port 8
Diodes NO DIDES
LED Option GREEN/GREEN
Latch UP
Number of Ports SINGLE PORT WITH SINGLE USB
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Speed 1000 BASE-T
Temperature 0 TO 70°C
Turns Ratio RX 1CT:1
Turns Ratio TX 1CT:1
