Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: HR983363C
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/60K
Price: $0.11-$24
Packaging Details: Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 180K/Month
Spec: |
HR983363C |
LED: |
Orange , Green / Yellow |
PCB Mounting Orientation: |
Side Entry (Right Angle) |
Connector: |
Jack Female |
Port Configuration: |
Single With Dual USB |
Application: |
LPJU4111AONL => HR983363C |
Spec: |
HR983363C |
LED: |
Orange , Green / Yellow |
PCB Mounting Orientation: |
Side Entry (Right Angle) |
Connector: |
Jack Female |
Port Configuration: |
Single With Dual USB |
Application: |
LPJU4111AONL => HR983363C |
|
|
|
Specifications
| Part Number | HR983363C |
| LINK-PP Part Number | LPJU4111AONL |
| AutomDX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u"/50u" |
| Cores Per Port | 4 |
| Diodes | NO DIDES41 |
| LED Option | WITH LEDS |
| Latch | UP/DOWN |
| Number of Ports | SINGLE PORT WITH DUAL USB |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | WITH OR WITHOUT |
| Speed | 10/100 BASE-T |
| Temperature | 0 TO 70°C/-40 TO 85°C |
| Turns Ratio RX | 1CT:1 |
| Turns Ratio TX | 1CT:1 |
