LPJK7436AHNL Signle Port Low-Profile RJ45 Jack 10/100/1000Base-T

China LPJK7436AHNL Signle Port Low-Profile RJ45 Jack 10/100/1000Base-T supplier
LPJK7436AHNL Signle Port Low-Profile RJ45 Jack 10/100/1000Base-T supplier LPJK7436AHNL Signle Port Low-Profile RJ45 Jack 10/100/1000Base-T supplier

Large Image :  LPJK7436AHNL Signle Port Low-Profile RJ45 Jack 10/100/1000Base-T

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: LPJK7436AHNL

Payment & Shipping Terms:

Minimum Order Quantity: 200/500/1200
Price: Supportive
Packaging Details: 60pcs/tray,or Reel Package
Delivery Time: Stock or 4-5 weeks
Payment Terms: TT,Paypa,West Union
Supply Ability: 2800K-PCS/Month
Contact Now
Detailed Product Description
PN: LPJK7436AHNL Speed: 1000 Base-T
LED: GREEN/YELLOW Cores: 8
Temperature: -40 TO + 85 File: PDF/3D/ISG/Stp/Step/Datasheet

LPJK7436AHNL Signle Port Low-Profile RJ45 Jack 10/100/1000Base-T

  1. 1X1 Tab-up  Rj 45 Jack LPJK7436AHNL
  2. Industrial Rj45 Low Profile
  3. 10/100/1000m Rj 45 Jack
  4. Shielded Rj 45 Jack
  5. Low profile Rj 45 Jack
Single Port Low Profile RJ45 Connector with 1000 Base-T Integrated Magnetics,ORANGE&GRREN/YELLOW LED,Tab Up,RoHS
LINK-PP Part Number LPJK7436AHNL
Application-Lan ETHERNET(NoN PoE)
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port 8
Diodes NO DIODES
LED Option GRREN/YELLOW
Latch TAB UP
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (mm) 11.30
Package Length (mm) 24.04
Package Width (mm) 16.85
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Speed 1000 BASE-T
Temperature -40 TO +85℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT

 LPJK7436AHNL Signle Port Low-Profile RJ45 Jack 10/100/1000Base-T


1. Product Type Features:
  1) Product Type = Connector
  2) Jack Type = RJ45
  3) Profile = Standard
  4) PCB Mounting Orientation = Side Entry (Right Angle)
2. Mechanical Attachment:
  1) Jack Configuration = 1 x 1
3. Electrical Characteristics:
  1) Shielded = Yes
4. Termination Related Features:
  1) EMI Finger - Bottom = Without
  2) Termination Method = Solder
5. Body Related Features:
  1) Port Configuration = Single/Multi
  2) EMI Fingers -Top and Sides = With/ Without
  3) Latch Orientation = Standard - Latch Down
  4) PCB Tail Length
6. Contact Related Features:
  1) Preloaded = Yes
  2) Contact Termination Type = Through Hole
7. Housing Related Features:
  1) Connector Style = Jack
8. Industry Standards:
  1) RoHS/ELV Compliance = RoHS compliant, ELV compliant
  2) Lead Free Solder Processes = Wave solder capable to 240°C,
      Wave solder capable to 260°C, Wave solder capable to 265°C
  3) RoHS/ELV Compliance History = Always was RoHS compliant
9. Identification Marking:
  1) Left LED Color (Position #1) = Green - 250 ohm resistor
  2) Right LED Color (Position #2) = Green - 250 ohm resistor
10. Conditions for Usage:
  1) Applies To = Printed Circuit Board
  2) Environmental Conditions = Office / Premises
  3) Operating Temperature (°C ) = 0 - 70/-40 - +85
