Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH
Model Number: LPJE1606DNL
Payment & Shipping Terms
Minimum Order Quantity: 200/500 PCS
Price: Supportive
Packaging Details: Reel/Carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Original: |
ARJ11A-MASD-MU-2 |
Equivalent: |
LPJE1606DNL |
Original Munafactuer: |
LINK-PP |
Termination: |
Solder |
Samples: |
Available 2 Pcs |
File: |
PDF/3D/ISG/Stp/Step/Datasheet |
Original: |
ARJ11A-MASD-MU-2 |
Equivalent: |
LPJE1606DNL |
Original Munafactuer: |
LINK-PP |
Termination: |
Solder |
Samples: |
Available 2 Pcs |
File: |
PDF/3D/ISG/Stp/Step/Datasheet |
10P10C SMT 1x1 Port RJ45 Magjack Connector without Integrated Magnetics,without LED,Tab Down,RoHS | |
LINK-PP Part Number | LPJE1606DNL |
Abracon LLC Part Number | ARJ11A-MASD-MU-2 |
Application-Lan | ETHERNET(NoN PoE) |
AutomDX | YES |
Bst Circuit | YES |
Configuration RX | T,C |
Configuration TX | T,C |
Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
Cores per Port | - |
Diodes | NO DIODES |
LED Option | Without LEDs |
Latch | TAB Down |
Number of Ports | 1X1 |
PCB | FR4 |
PCB Mount Angle | Surface Mount |
PCB Retaining Post | T POST |
Package Height (Inches) | 0.463 |
Package Height (mm) | 11.75 |
Package Length (Inches) | 0.734 |
Package Length (mm) | 18.65 |
Package Width (Inches) | 0.620 |
Package Width (mm) | 15.74 |
Pin Type | THT SOLDER |
RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
Search | YES |
Shield EMI Tabs | Shielded |
Speed | RJ45 Without Magnetics |
Temperature | -40 TO + 85℃ |
Turns Ratio RX | 1CT:1CT |
Turns Ratio TX | 1CT:1CT |
