JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics

China JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics supplier
JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics supplier JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics supplier

Large Image :  JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics

Product Details:

Place of Origin: China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: JD0-0009NL

Payment & Shipping Terms:

Minimum Order Quantity: 200/500/1200
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock or 3-4 weeks
Payment Terms: TT,Paypa,West Union
Supply Ability: 4600K.PCS/Month
Contact Now
Detailed Product Description
Product Name: JD0-0009NL TAB Direction: Down
Mounting: THT PCB Mounting LED Indicator: GREEN & YELLOW
Samples: Free File: PDF/3D/ISG/Stp/Step/Datasheet

JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics



Pulse Part Number JD0-0009NL
Application-Lan ETHERNET(NoN PoE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Diodes NO DIODES
LED Option GREEN & YELLOW
Latch TAB DOWN
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.531
Package Height (mm) 13.50
Package Length (Inches) 0.840
Package Length (mm) 21.35
Package Width (Inches) 0.627
Package Width (mm) 15.93
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Speed 10/100BASE-T
Temperature 0 TO 70℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT



Why Choose Us

World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers

100% Guarantee Qualtiy
• Manufactured Under Strict Controls.
• 100% Tested (Not Just Batch Tested)
• LINK-PP Is OEM Of TE (Tyco) For 9 Years
• Successful Customer: Texas Instruments Samsung Cisco Siemens And Intel…
• LINK-PP Is The Preferred Supplier Of TI (Texas Instruments)
• Quality Guarantee:6 Years


Competitive Price And Service
• More Competitive Price Than Pulse Tyco Halo And Amphenol
• Free Samples Are Available
• Provide New Design For Customer Requirements
• 90% Off Shipping Cost By DHL UPS DEDEX Or TNT
• Delivery Time:2-3 Weeks After Orders



Professional Certification

JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T MagneticsJD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics

JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T MagneticsJD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics

JD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T MagneticsJD0-0009NL Single Port RJ45 Jack with 10 / 100 Base-T Magnetics


Applications:

Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem
