JD0-0011NL One Port RJ45 Jack with 10 / 100 Base-T Magnetics Side Entry

China JD0-0011NL One Port RJ45 Jack with 10 / 100 Base-T Magnetics Side Entry supplier
JD0-0011NL One Port RJ45 Jack with 10 / 100 Base-T Magnetics Side Entry supplier JD0-0011NL One Port RJ45 Jack with 10 / 100 Base-T Magnetics Side Entry supplier JD0-0011NL One Port RJ45 Jack with 10 / 100 Base-T Magnetics Side Entry supplier

Large Image :  JD0-0011NL One Port RJ45 Jack with 10 / 100 Base-T Magnetics Side Entry

Product Details:

Place of Origin: China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: JD0-0011NL

Payment & Shipping Terms:

Minimum Order Quantity: 200/500/1200
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock or 3-4 weeks
Payment Terms: TT,Paypa,West Union
Supply Ability: 4600K.PCS/Month
Contact Now
Detailed Product Description
Product Name: JD0-0011NL TAB Direction: Down
Mounting: THT PCB Mounting LED Indicator: LED Colors Can Be Selected
Samples: Free File: PDF/3D/ISG/Stp/Step/Datasheet

JD0-0011NL One Port RJ45 Jack with 10 / 100 Base-T Magnetics Side Entry



Single Port RJ45 Connector with 10/100 Base-T Integrated Magnetics,Green/Yellow LED,Tab Down,RoHS
LINK-PP Part NumberLPJxxxxxxNL
Pulse Part NumberJD0-0011NL
Application-LanETHERNET(NoN PoE)
AutomDXYES
Bst CircuitYES
Configuration RXT,C
Configuration TXT,C
Contact Mating Area PlatingGOLD 6u"/15u"/30u"
Cores per Port4
DiodesNO DIODES
LED OptionGREEN/YELLOW
LatchTAB DOWN
Number of Ports1X1
PCBFR4
PCB Mount AngleSIDE ENTRY
PCB Retaining PostT POST
Package Height (Inches) 0.531
Package Height (mm) 13.50
Package Length (Inches) 0840
Package Length (mm) 21.35
Package Width (Inches) 0.627
Package Width (mm) 15.93
Pin TypeTHT SOLDER
RoHS CompliantYES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
SearchYES
Shield EMI TabsWITH
Speed10/100 BASE-T
Temperature0 TO 70℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT
Description:

1X1  RJ45 Magjack with/without leds, meeting IEEE 802.3u
1. Product Type Features:
  1) Product Type = Connector
  2) Jack Type = RJ45
  3) Profile = Standard
  4) PCB Mounting Orientation = Side Entry (Right Angle)
2. Mechanical Attachment:
  1) Jack Configuration = 1 x 1
3. Electrical Characteristics:
  1) Shielded = Yes
4. Termination Related Features:
  1) EMI Finger - Bottom = Without
  2) Termination Method = Solder
5. Body Related Features:
  1) Port Configuration = Single/Multi
  2) EMI Fingers -Top and Sides = With/ Without
  3) Latch Orientation = Standard - Latch Down
  4) PCB Tail Length
6. Contact Related Features:
  1) Preloaded = Yes
  2) Contact Termination Type = Through Hole/Surface Mount
7. Housing Related Features:
  1) Connector Style = Jack
8. Industry Standards:
  1) RoHS/ELV Compliance = RoHS compliant, ELV compliant
  2) Lead Free Solder Processes = Wave solder capable to 240°C,
      Wave solder capable to 260°C, Wave solder capable to 265°C
  3) RoHS/ELV Compliance History = Always was RoHS compliant
9. Identification Marking:
  1) Left LED Color (Position #1) = Green - 250 ohm resistor
  2) Right LED Color (Position #2) = Green - 250 ohm resistor
10. Conditions for Usage:
  1) Applies To = Printed Circuit Board
  2) Environmental Conditions = Office / Premises
  3) Operating Temperature (°C ) = 0 - 70/-40 - +85


Successful customer
• Texas Instruments
LINK-PP is the preferred supplier of TI. Welcome to visit the TI website, you will look at our logo "LINK-PP" on BeagleBone Board.
J8064D668ANL 1X6 8p8c RJ45 Connector with 10/100 Base-T Integrated Magnetics



Applications:
Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem

Competitive Advantage:
2600 staff,
100% test
Flexible delivery time
