JK0-5101NL Single Port RJ45 Female Connector with 5G Base-T

JK0-5101NL Single Port RJ45 Female Connector with 5G Base-T
JK0-5101NL Single Port RJ45 Female Connector with 5G Base-T
video play

Large Image :  JK0-5101NL Single Port RJ45 Female Connector with 5G Base-T

Product Details:
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: JK0-5101NL
Payment & Shipping Terms:
Minimum Order Quantity: 50/500/1000/25K
Price: $0.5-$3.5
Packaging Details: Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 180K/Month
Detailed Product Description
Part Number: JK0-5101NL Mounting: DIP / Side Entry
Application: 5GBase-T Indicators: Green/Yellow LEDs
Samples: Available File: PDF/3D/ISG/Stp/Step/Datasheet
High Light:

rj45 magnetic jack

,

shielded rj45 plugs

JK0-5101NL Single Port RJ45 Female Connector with 5G Base-T

Shielded 1x1 Port RJ45 Female Connector with 5G Base-T Integrated Magnetics,Green/Yellow &Green LED,Tab UP,RoHS
Pulse Part Number JK0-5101NL
Application-Lan ETHERNET(NoN PoE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port 8
Diodes NO DIODES
LED Option GREEN/YELLOW & GREEN
Latch TAB UP
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.546
Package Height (mm) 13.868
Package Length (Inches) 1.30
Package Length (mm) 33.020
Package Width (Inches) 0.661
Package Width (mm) 16.789
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs With
Speed 5G BASE-T
Temperature 0 TO +70℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT
