Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: ARJM11D7-809-JJ-CW4
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.5-$3.5
Packaging Details: Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 180K/Month
Specification: |
ARJM11D7-809-JJ-CW4 |
Part PN: |
LPJXXXXXNL |
Ethernet: |
Category 5 |
Project Application: |
Networking Solutions |
LEDs: |
Green, Yellow - Green, Yellow |
Samples: |
Can Be Free |
Specification: |
ARJM11D7-809-JJ-CW4 |
Part PN: |
LPJXXXXXNL |
Ethernet: |
Category 5 |
Project Application: |
Networking Solutions |
LEDs: |
Green, Yellow - Green, Yellow |
Samples: |
Can Be Free |
| Part Status | Active | |
|---|---|---|
| Connector Type | RJ45 | |
| Number of Ports | 1 | |
| Number of Rows | 1 | |
| Applications | 2.5G Base-T, AutoMDIX | |
| Mounting Type | Through Hole | |
| Orientation | 90° Angle (Right) | |
| Termination | Solder | |
| Height Above Board | 0.543" (13.80mm) | |
| LED Color | Green, Yellow - Green, Yellow | |
| Number of Cores per Jack | 8 | |
| Shielding | Shielded | |
| Features | Board Lock | |
| Tab Direction | Up | |
| Contact Material | - | |
| Contact Finish | Gold | |
| Operating Temperature | 0°C ~ 70°C | |
| Contact Finish Thickness | 30.0µin (0.76µm) | |
| Shield Material | - | |
| Dielectric Material | - |
