ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T 1X1 Port Rj45 Modular Jack 5G

China ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T 1X1 Port Rj45 Modular Jack 5G supplier
ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T 1X1 Port Rj45 Modular Jack 5G supplier ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T 1X1 Port Rj45 Modular Jack 5G supplier

Large Image :  ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T 1X1 Port Rj45 Modular Jack 5G

Product Details:

Place of Origin: China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH
Model Number: ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T

Payment & Shipping Terms:

Minimum Order Quantity: 200/500//1200
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock or 3-4 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 4200K-PCS/Month
Contact Now
Detailed Product Description
Specifications: ARJM11A3-811-JJ-ER4-T Cores: 8
Apllication: 5G Base-Tx Original Munafactuer: LINK-PP
Samples: Free

ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T 1X1 Port Rj45 Modular Jack 5G

1x1 Port 8P8C RJ45 Jack Connector with 5G Base-T Integrated Magnetics, Green&Yellow/Green&Yellow LED,Tab Down,RoHS
LINK-PP Part Number LPJGxxxxNL
Abracon LLC Part Number ARJM11A1-811-JJ-ER4-T / ARJM11A3-811-JJ-ER4-T
Application-Lan ETHERNET(NoN PoE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port 8
Diodes NO DIODES
LED Option Green&Yellow/Green&Yellow LEDs
Latch TAB Down
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.535
Package Height (mm) 13.60
Package Length (Inches) 0.839
Package Length (mm) 21.30
Package Width (Inches) 0.626
Package Width (mm) 15.90
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs With
Speed 5G Base-T
Temperature -40°C ~ 85°C
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT



APPLICATIONS:

  • Point of Sale and Kiosk Computers
  • Vector Network Analyzers
  • CompactPCI and PXI Products
  • VME, VPX, and VXI Extenders
Main Customer
Design for Ti , Intel , Samsung , Fluke , Jabil , Flextronics ,Cypress, Freescale,EKF.......

J3011G21DNLT SMT 1x1 Port RJ45 Magjack Connector With 10/100M

J3011G21DNLT SMT 1x1 Port RJ45 Magjack Connector With 10/100M

EMS ApplicationBuilt-in Flexible PCB Assembly; Rigid-Flexible PCB Assembly; Microelectronic, Flip Chip; Microelectronic, Chip On Board; Optoelectronic Assembly; RF / Wireless Assembly; Through Hole Assembly; Surface Mount Assembly; System Assembly; Printed Circuit Board Assembly



Other Part Number

ARJM11B1-811-KK-ER2-T
ARJM11A3-811-JJ-ER2-T
ARJM11B3-811-JJ-ER2-T
ARJM11A3-811-KK-ER2-T
ARJM11B3-811-KK-ER2-T
ARJM11A1-811-AB-ER4-T
ARJM11A1-811-AD-ER4-T
ARJM11B1-811-AB-ER4-T
ARJM11B1-811-AD-ER4-T
ARJM11A3-811-AB-ER4-T
ARJM11A3-811-AD-ER4-T
ARJM11B3-811-AB-ER4-T
ARJM11B3-811-AD-ER4-T
ARJM11C7-811-AB-CW2
ARJM11D7-811-AB-CW2
