ARJM22A1-A12-NN-CW2 2x2 Ethernet Stacked Rj45 Jack Without LED 10/100 Base - T

China ARJM22A1-A12-NN-CW2 2x2 Ethernet Stacked Rj45 Jack Without LED 10/100 Base - T supplier
ARJM22A1-A12-NN-CW2 2x2 Ethernet Stacked Rj45 Jack Without LED 10/100 Base - T supplier ARJM22A1-A12-NN-CW2 2x2 Ethernet Stacked Rj45 Jack Without LED 10/100 Base - T supplier

Large Image :  ARJM22A1-A12-NN-CW2 2x2 Ethernet Stacked Rj45 Jack Without LED 10/100 Base - T

Product Details:

Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH
Model Number: ARJM22A1-A12-NN-CW2

Payment & Shipping Terms:

Minimum Order Quantity: 300
Price: Supportive&Competitive
Packaging Details: 18PCS/Tray,18Trays/Carton= 324PCS= 37*30*30CM=11KG
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000000/Month
Contact Now
Detailed Product Description
Part No: ARJM22A1-A12-NN-CW2 Specification: LPJXXXXNL
Ethernet: Cat5/5e Mounting: Thru-hole
Termination: Solder Samples: Available

ARJM22A1-A12-NN-CW2 2x2 Ethernet Stacked Rj45 Jack Without LED 10/100 Base - T



2X2 Ethernet RJ45 Connector with 10/100 Base-T Integrated Magnetics ,Without LED,Tab Up/Tab Down,RoHS
LINK-PP Part Number LPJxxxxNL
Abracon LLC Part Number ARJM22A1-A12-NN-CW2
Application-Lan ETHERNET(NoN PoE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port 4
Diodes NO DIODES
LED Option WITHOUT LEDS
Latch TAB UP/TAB DOWN
Number of Ports 2X2
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 1.004
Package Height (mm) 25.50
Package Length (Inches) 1.108
Package Length (mm) 28.14
Package Width (Inches) 1.226
Package Width (mm) 31.14
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Speed 10/100 Base-T
Temperature 0°C ~ 70°C
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT



Application Range

• Audio / Video product:MP3, MP4, DVD, stereo system

• Digital devices: digital camera, digital video

• Remote control: Vehicle, rolling door, Home security products

• Communication products: mobiles, car telephone, telephone, building equipment, PDA etc.

• Household Appliances: TV, microwave oven, electric cooker, electric hair drier, electronic scale, Body Fat &Water Scale, Kitchen Scale.

• Security Products: Videophone, Monitor etc.

• Toy: electronic toy etc.

• Computer products: Camera, recording pen etc.

• Fitness equipment: running machine, massage chair, timer etc.

• Medical Equipment: sphygmomanometer, thermometer, the hospital call system and other similar products.
