Home > products > SMT RJ45 Connector > 634108185321 Unshielded 1X1 SMT Antenna Connector Tab Down LPJE29972NNL

634108185321 Unshielded 1X1 SMT Antenna Connector Tab Down LPJE29972NNL

Product Details

Place of Origin: China

Brand Name: LINK-PP

Certification: ISO 9001,ISO 14001,UL,SGS,REACH

Model Number: 634108185321

Payment & Shipping Terms

Minimum Order Quantity: 200/500//1200

Price: Supportive&Competitive

Packaging Details: 50pcs/tray,1200pcs/carton

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 4200K-PCS/Month

Get Best Price
Highlight:

surface mount rj45 connector

,

ultra low profile jack

Part Number:
634108185321
Original Munafactuer:
LINK-PP
Application:
Cat5/6e
Termination:
Solder
Type:
DIP / Side Entry
Archivi Disponibili:
PDF/3D/ISG/Stp/Step/Datasheet
Part Number:
634108185321
Original Munafactuer:
LINK-PP
Application:
Cat5/6e
Termination:
Solder
Type:
DIP / Side Entry
Archivi Disponibili:
PDF/3D/ISG/Stp/Step/Datasheet
634108185321 Unshielded 1X1 SMT Antenna Connector Tab Down LPJE29972NNL
634108185321 Unshielded 1X1 SMT RJ45 Modular Jack Tab Down LPJE29972NNL


SMD RJ45 8P8C Connector without Integrated Magnetics,wihtout LED,Tab Up,RoHS
LINK-PP Part Number LPJE29972NNL
Other Part Number 634108185321
Application-Lan ETHERNET
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port NON
Diodes NO DIODES
LED Option Without
Latch TAB UP
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.50
Package Height (mm) 12.70
Package Length (Inches) 0.657
Package Length (mm) 16.70
Package Width (Inches) 0.60
Package Width (mm) 15.25
Pin Type SURFACE MOUNT
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITHOUT
Speed -
Temperature -40 TO +85℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT
