LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated

China LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated supplier
LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated supplier LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated supplier LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated supplier LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated supplier LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated supplier

Large Image :  LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated

Product Details:

Place of Origin: China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: RG111Q066AA2A1D

Payment & Shipping Terms:

Minimum Order Quantity: 200/500//1200
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 4200K-PCS/Month
Contact Now
Detailed Product Description
Specification: RG111Q066AA2A1D Ethernet: 1x1000Mbps
Mounting: R/A Shield Samples: Available
File: PDF/3D/ISG/Stp/Step/Datasheet Configuration RX: T,C
High Light:

stacked rj45 connectors

,

rj45 magnetic jack

LPJG4806HENL 10/100/1000 BASE-T RJ45 Modular Jack RG111Q066AA2A1D


Single Port RJ-45 Modular Connector with 10/100/1000 Base-T Integrated Magnetics,Green/Yellow LED,Tab Down,RoHS
LINK-PP Part Number LPJG4806HENL
Other Part Number RG111Q066AA2A1D
Application-Lan ETHERNET(NoN PoE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port 8
Diodes NO DIODES
LED Option GREEN/YELLOW
Latch TAB DOWN
Number of Ports 1X1
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.524
Package Height (mm) 13.30
Package Length (Inches) 0.837
Package Length (mm) 21.25
Package Width (Inches) 0.627
Package Width (mm) 15.93
Pin Type THT SOLDER
RoHS Compliant YES
Search YES
Shield EMI Tabs WITHOUT
Speed 10/100/1000 BASE-T
Temperature -40 TO 85℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT



• Texas Instruments

LINK-PP is the preferred supplier of TI. Welcome to visit the TI website, you will look at our logo "LINK-PP" on BeagleBone Board.

LPJG4806HENL 10/100/1000 BASE-T RJ45 Magnetic Jack RG111Q066AA2A1D Integrated 0


Applications:


Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem

Competitive Advantage:

16 years production experience,
2600 staff,
100% test
Flexible delivery time


FAQ

Q: Are you a factory or a trading company?

A: We are factory with 6 production line assembled workshop and a Stamping Workshop,about 200 employees.

Q: Can I get some samples?

A: Yes, sample order is available, some samples are free. and it will be freight collect payment.

Q : How long is your lead time?

A: Normally, our lead time is 10-25 days according to different products.

Q: What's your payment term?

A: We accept TT/LC/DP/DA/Paypal/Western Union/MoneyGram

Q: Why choose our company?

A: 1. Professional manufacturer since 1997, provide various kinds of connectors and LAN Transformer
2. No MOQ demand.
3. Good quality, competitive price with best service.
4. Available for ODM/OEM order.
