Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH
Model Number: 7499131440
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.11-$12
Packaging Details: Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 208K/Month
Part Number: |
7499131440 |
Samples: |
Active&Available |
Category: |
Multi-port RJ45 |
Interface: |
1000Mbps |
Port: |
1x4 Port |
Made In China: |
LPJG46963-8A4NL-2 |
Part Number: |
7499131440 |
Samples: |
Active&Available |
Category: |
Multi-port RJ45 |
Interface: |
1000Mbps |
Port: |
1x4 Port |
Made In China: |
LPJG46963-8A4NL-2 |
| Shielded 1x4 Port RJ45 Magjack Connector without Integrated Magnetics,without LED,Tab Down,RoHS | |
| LINK-PP Part Number | LPJG46963-8A4NL-2 |
| Molex Part Number | 7499131440 |
| Application-Lan | ETHERNET(NoN PoE) |
| AutomDX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Cores per Port | 8 |
| Diodes | NO DIODES |
| LED Option | GREEN&YELLOW/GREEN&YELLOW |
| Latch | TAB Down |
| Number of Ports | 1X4 |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Package Height (Inches) | 0.537 |
| Package Height (mm) | 13.65 |
| Package Length (Inches) | 0.837 |
| Package Length (mm) | 21.27 |
| Package Width (Inches) | 2.325 |
| Package Width (mm) | 59.05 |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | WITHOUT |
| Speed | 1000 BASE-T |
| Temperature | -40 TO 85℃ |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
