Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: HST-96206DR
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
LINK-PP P/N: |
HST-96206DR |
Familiy: |
10/100/1000 Magnetics |
Mounting: |
DIP |
Samples: |
Available |
Number Of Ports: |
Single |
Hi-pot: |
1500Vrms |
OCL: |
350uh Min |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
LINK-PP P/N: |
HST-96206DR |
Familiy: |
10/100/1000 Magnetics |
Mounting: |
DIP |
Samples: |
Available |
Number Of Ports: |
Single |
Hi-pot: |
1500Vrms |
OCL: |
350uh Min |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
● Designed for long haul Gigabit Ethernet 100/1000Base-T,full Quad channals applications.
● Supports PoE+ and Auto MDIX in 16 pairs of category 5 UTP cable.
● Cable interface for isolation and low common mode emissions.
● Compliant with IEEE 802.3at standard for 1000Base-T.
Detailed Information:
| Single Port, 10/100/1000 BASE-T Ethernet Transformer Modules, SMD,Rohs | |
| Part Number | HST-96206DR |
| Speed | 10/100/1000 BASE-T |
| Number of Ports |
Single |
| Application - LAN | ETHERNET (PoE+) |
| Package | DIP |
| AutomDX | YES |
| Comment | SAME AS NL VERSION |
| Configuration RX | T,C,S |
| Configuration TX | T,C,S |
| Construction | OPEN FRAME |
| Cores Per Port | 32 |
| Package Height (Inches) | - |
| Package Height (mm) |
16.90 |
| Package Length (Inches) | - |
| Package Length (mm) | 28.10 |
| Package Width (Inches) | - |
| Package Width (mm) | 27.30 |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
Product Lines
Now has 22 production lines, using IE technology to analyze the process statistics, continuously improve the production process and technology, improve production efficiency.
FAQ
1.Are you the real manufacturer?
Yes. We are the real manufacturer since 1997.
2.Can you accept small order?
Yes, small order is available .We support new project of our customers as we know business is always from
small order.
3.Which kind of certification you have ?
ISO9001, SGS, UL, RoHs.
4.What is your delivery time?
Usually within 2-3 working days
5.What is your payment way?
T/T, L/C, D/P,MoneyGram,Western Union and Paypal.
6.Can you supply customized products and logo?
-Yes. We supply OEM&ODM service. You can send us your drawing.
