Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: RM3-KA-0005
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.05-$1.28
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4200K-PCS/Month
Part Number: |
RM3-KA-0005 |
Mass Production: |
LPJ17003-8AENL |
Original Munafactuer: |
LINK-PP |
Application: |
1000Base-T |
Termination: |
Solder |
LEDs: |
GREEN/YELLOW&GREEN |
Part Number: |
RM3-KA-0005 |
Mass Production: |
LPJ17003-8AENL |
Original Munafactuer: |
LINK-PP |
Application: |
1000Base-T |
Termination: |
Solder |
LEDs: |
GREEN/YELLOW&GREEN |
| Category | |
| Category | RJ45 connector -PCB Socket 8P8C (DIP) |
| Filter | 1000 Base-T |
| Entry Angle | 90° Angle |
| LED | Green/Yellow&Green |
| Color - Resin | Black |
| Electrical | |
| Current - Maximum per Contact | 1.50A |
| Voltage - Maximum | 125V |
| Contact Resistance | 30 mΩ Max |
| Insulation Resistance | 500 MΩ Min |
| Withstanding Voltage | 1000V AC r.m.s |
| Temperature Range operating | 0ºC~+70ºC |
| Material and Plating | |
| Material-Metal | Phosphor Bronze |
| Material - Plating Mating | Gold |
| Material - Plating Termination | Gold |
| Material - Resin | PBT UL94V-0 |
•Free Samples. •Delivery Time 1-2 Weeks.
LINK-PP Electronic SFPRJ45 Connector and LAN Transformer 10+ years of Manufacturing Experience.
Factory
•We have over 1000 workers.
•The area of ZhuSun is 60,000 square meters.
•Huizhou LINK-PP Electronics Co.,Ltd have owns 3 factory in sichuan,hubei,Zhejiang.
Quality
•Lean production management.
•100% Tested (Not Just Batch Tested).
•Quality Guarantee:5 Years.
Certification
•ISO 9001:2008,
•ROHS CE FCC Compliance
•Active Environmental Policy.
Have R&D dept
•OEM Service Offered,Design Service Offered.
•Engineer Can Design Products As You Need,Developer Tooling As Customer Require.
Price And Service
•Than PULSE TE HALO BEL Wurth Amphenol MOLXE BOTHHAND ABRACON FOXCONN And HANRUN More Competitive Price And Delivery.
Central Controller, Embedded Ethernet controller, Active Optical Network, Fingerprint Access Control, Industrial embedded communication controller, Intelligent monitoring equipment ,smarthome control systems,passive optical access networks, NETWORKED VIDEO INTEGRATION DEVICES, STORAGE SYSTEMS FOR IP VIDEO SURVEILLANCE,IP CAMERA INSTALLATION TOOLS,External Board Series...
