Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: HR931143C
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.05-$1.28
Packaging Details: Tray Package: Carton size 32*30*31cm , G.W/carton 8.5kg , Qty/carton 1200pcs , SPQ 50pcs
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 6000K/month
Spec: |
HR931143C |
Port: |
1x1 Female Rj45 |
Magnetics: |
1000 Base-T |
LED: |
Green/Yellow Leds |
Mounting: |
Right Angle |
Cross Ref: |
LPJG0843GENL |
File: |
PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters |
Spec: |
HR931143C |
Port: |
1x1 Female Rj45 |
Magnetics: |
1000 Base-T |
LED: |
Green/Yellow Leds |
Mounting: |
Right Angle |
Cross Ref: |
LPJG0843GENL |
File: |
PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters |
| Category | |
| Category | RJ45 connector -PCB Socket 8P8C (DIP) |
| Filter | 1000 Base-T |
| Entry Angle | 90° Angle |
| LED | Green/Yellow |
| Color - Resin | Black |
| Electrical | |
| Current - Maximum per Contact | 1.50A |
| Voltage - Maximum | 125V |
| Contact Resistance | 30 mΩ Max |
| Insulation Resistance | 500 MΩ Min |
| Withstanding Voltage | 1000V AC r.m.s |
| Temperature Range operating | 0ºC~+70ºC |
| Material and Plating | |
| Material-Metal | Phosphor Bronze |
| Material - Plating Mating | Gold |
| Material - Plating Termination | Gold |
| Material - Resin | PBT UL94V-0 |
•Free Samples. •Delivery Time 1-2 Weeks.
LINK-PP Electronic SFPRJ45 Connector and LAN Transformer 10+ years of Manufacturing Experience.
Factory
•We have over 1000 workers.
•The area of ZhuSun is 60,000 square meters.
•Yueqing ZhuSun Electronics Co.,Ltd have owns 3 factory in sichuan,hubei,Zhejiang.
Quality
•Lean production management.
•100% Tested (Not Just Batch Tested).
•Quality Guarantee:5 Years.
Certification
•ISO 9001:2008,
•ROHS CE FCC Compliance
•Active Environmental Policy.
Have R&D dept
•OEM Service Offered,Design Service Offered.
•Engineer Can Design Products As You Need,Developer Tooling As Customer Require.
Price And Service
•Than PULSE TE HALO BEL Wurth Amphenol MOLXE BOTHHAND ABRACON FOXCONN And HANRUN More Competitive Price And Delivery.
