Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: AGSC-48111S
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Specifications: |
AGSC-48111S |
Pin To Pin: |
LP6080NL |
Mounting: |
SMD |
Apllication: |
100/1000base-T POE(+) |
Dimension: |
28x15.40x7.00mm |
Temperature: |
0℃ TO + 70℃ |
Archivi Disponibil: |
PDF/3D/ISG/Stp/Step/Datasheet |
Specifications: |
AGSC-48111S |
Pin To Pin: |
LP6080NL |
Mounting: |
SMD |
Apllication: |
100/1000base-T POE(+) |
Dimension: |
28x15.40x7.00mm |
Temperature: |
0℃ TO + 70℃ |
Archivi Disponibil: |
PDF/3D/ISG/Stp/Step/Datasheet |
Product Features:
| Pin to Pin LP6080NL | |
| Mounting | Surface Mount |
| Family | 100/1000M POE/POE+ Magnetics |
| Transformer Type | Isolation Transformer |
| Minimum Crosstalk | -40@100MHz dB |
| Lead Style | Gull Wing |
| Package Type | SMD |
| Maximum OCL Inductance | 0.35 mH |
| Maximum Isolation Voltage | 1500 Vrms |
| Minimum CMRR | -40@1MHz to 100MHz dB |
| Minimum Return Loss | -10@100MHz dB |
| Turns Ratio | 1:1 |
| Operating Temperature | -40 to 85 °C |
| Packaging | Tape and Reel |
| Maximum Insertion Loss | -1.1@1MHz to 100MHz dB |
| Product Length | 28.00 mm |
|
|
Our Services:
20 Years Experience
Our company since 1997 RJ45 network connector production in th past 20 years,only focus on RJ45 network connector design and development and production and sales.
OEM Services
For high-quality, high reliability and reasonable price RJ45 network connector products,and more than the word’s top 500 OEM manufacturers recognized.
Production Ability
The company’s own injection molding, stamping and automated assembly plant, a professional automated production and testing equipment, the company has established an independent laboratory.
What's the Refund&Replacement?
If there are any quality problems, please make sure all these items must be returned in their original condition to qualify for a refund or replacement. (Any used or damaged items can not be refunded or replaced).
