Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: SGS, UL,CE, ISO9001:2008,REACH
Model Number: J8064D648ANL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.11-$12
Packaging Details: Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 208K/Month
Specification: |
J8064D648ANL |
Cross PN: |
LPJ46204AENL |
Ethernet: |
1x4 10/100 |
Gender: |
Female |
Mouting: |
Thru-hole |
Samples: |
Available |
Specification: |
J8064D648ANL |
Cross PN: |
LPJ46204AENL |
Ethernet: |
1x4 10/100 |
Gender: |
Female |
Mouting: |
Thru-hole |
Samples: |
Available |
|
|
| Electrical Specification @25℃ 1.Turns Ratio(±2%): TX=1CT:1CT RX=1CT:1CT 2.OCL: 350uH Min @100KHz,0.1V,8mA DC Bias 3.Insertion Loss: 1～100MHz:-1.0dB Max 4.Return Loss(dB Min): 1～30MHz:-16 30～60MHz:-12 60～80MHz:-10 5.Crosstalk(dB Min): 1～30MHz:-40 30～60MHz:-35 60～100MHz:-30 6.CMR(dB Min): 1～50MHz:-40 50～150MHz:-30 7.Hipot: 1500V AC 6S 1mA 8.Operating Temperature: 0℃～70℃. |
|
