Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Original: |
2170744-4 |
Connector Type: |
QSFP28 Cage |
Part Status: |
Active |
Data Rate (Max) (Gb/s): |
28 Gb/s |
File: |
PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters |
Lifecycle: |
More Than 20Years |
Original: |
2170744-4 |
Connector Type: |
QSFP28 Cage |
Part Status: |
Active |
Data Rate (Max) (Gb/s): |
28 Gb/s |
File: |
PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters |
Lifecycle: |
More Than 20Years |
| Part Number | 2170744-4 |
|---|---|
| Part Status | Active |
| Connector Type | QSFP28 |
| Connector Style | Cage, Ganged (1 x 4) |
| Number of Ports | 1X4 port |
| Included Lightpipe | NO |
| PCB Mounting Style | Through Hole - Press-Fit |
| Data Rate (Max) | 28 Gb/s |
| Features | EMI Shielded |
| Operating Temperature Range | -40 – 85 °C |
| PCB Thickness (Recommended) | 1.57 mm [ .062 in ] |
| Tail Length | 2.05 mm [ .081 in ] |
| Cage Material | Nickel Silver |
| EMI Containment Feature Type | EMI Springs |
| Circuit Application | Signal |
| Pluggable I/O Applications | SFP+ Stacked Belly-to-Belly |
| You may be interesting in below considerate supports: | ||||
| Datasheet | Request by email to | contact us | ||
| Samples | Free | For Free samples delivery, pls advise below infomation For Shipping | ||
| Company Name | ||||
| Delivery Address | ||||
| Telephone Number | ||||
| Contact Person | ||||
| UPS/DHL/Fedex/TNT A.C | (If available) | |||
| Trial Production | U/P(USD) | $0.09-$1.85 | We can ship out parts directly to your warehouse/door to door | |
| L/T(Weeks) | Stock | |||
| Shipping Term | DAP/CIF/FCA/FOB | |||
| Mass Production | U/P(USD) | Stock | ||
| L/T(Weeks) | Stock | |||
| Shipping Term | DAP/CIF/FCA/FOB | |||
| Lifecycel | More than 20 years | You can use our parts for long term consideration | ||
| Reject Ratio | Zero Defective (100% Tested) | |||
| Special Services | Accept customized service | Accept revised designing | ||
| Now you can contact us instantly |
||||
What Is QSFP28 ?
QSFP28 (quad small form-factor pluggable 28) is designed for 100G applications.
It offers four channels of high-speed differential signals with data rates ranging from
25 Gbps up to potentially 40 Gbps, and finally, meet 100 Gbps Ethernet (4×25 Gbps)
and 100 Gbps 4X InfiniBand Enhanced Data Rate (EDR) requirements. Note that,
QSFP28 can do 4x25G and 2x50G breakout connection, or 1x100G depending on
the transceiver type that is used.
2170744-4 QSFP28 Cage 1x4 Port 28 Gb/s Through Hole Drawing:
2170744-4 Description:
| 2284170-1 | 2007251-1 | 2007181-1 |
| 2007132-1 | 2007180-1 | 2110069-1 |
| 2170744-4 | 2170805-1 | 2169260-1 |
| 2057555-1 | 2300275-1 | 2338495-3 |
| 2170746-2 | 2170805-5 | 2007250-1 |
What is the difference between QSFP56 and QSFP28?
