HB5006HLT HXB5008HLT LAN Magnetic Transformer IEEE 802.3ab/af Standards

Name: HB5006HLT HXB5008HLT LAN Magnetic Transformer IEEE 802.3ab/af Standards
Brand: LINK-PP INT'L TECHNOLOGY CO., LIMITED
SKU: HB5006HLT
Price: 0.08 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: HB5006HLT

Payment & Shipping Terms

Minimum Order Quantity: 50pcs

Price: $0.08-$2.02

Packaging Details: Reel

Delivery Time: Ships within 15 days

Payment Terms: TT, NET30/60/90 Days

Supply Ability: 6000K-PCS/Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                    HB5006HLT LAN Transformer, HXB5008HLT, PoE SMD Pulse Transformer


Product Name:	PoE Ethernet Transformer	Number Of Channels/Ports:	SINGLE
PoE Power:	30W PoE 4 Pair	Data Rate:	1Gigabit
Maximum Peak Solder Temperature:	245°C	Moisture Sensitive Level:	1

Product Name:	PoE Ethernet Transformer
Number Of Channels/Ports:	SINGLE
PoE Power:	30W PoE 4 Pair
Data Rate:	1Gigabit
Maximum Peak Solder Temperature:	245°C
Moisture Sensitive Level:	1

HB5006HLT HXB5008HLT LAN Magnetic Transformer IEEE 802.3ab/af Standards

HB5006HLT HXB5008HLT 1000base T Transformer Description:

Pulse HB and HXB series SMD Magnetic Modules are designed for Power over Ethernet (PoE) applications. It is a Single PortLAN transformer that supports a 1Gigabit Data Rate and is suitable for IP cameras, wireless access points, and VoIP phones.
As the leading Chinese manufacturer of Gigabit Ethernet transformers, LINK-PP designs replacements for HB5006HLT HXB5008HLT PoE transformers at a more reasonable price. Fully compliant with RoHS and Halogen-free regulations, our transformer boasts a low profile and compact footprint. It supports a 4-pair 30 watts of power over Ethernet. Meeting or exceeding IEEE802.3ab/af standards for 1000Base-T, it is also Compatible with all 1:1 turns ratio PHYs. Designed to withstand both commercial and industrial temperature conditions, our transformers are reliable and durable.

Key Features:

The Transformer features a single port and a compact, low-profile design, making it ideal for space-constrained applications.
HB5006HLT supports 30W PoE power and is a reliable and efficient solution for your PoE needs.
This product meets IEEE802.3ab and IEEE802.af standards for 1000Base-T Ethernet connections.
The Operating Temperature of the commercial grade HB5006HLT is 0-70°C, and the operating temperature of the industrial grade HXB5008HLT is -40°C to +85°C.
Does not contain any harmful substances, it’s safe for your equipment and the environment
This POE LAN transformer utilizes reliable surface mount device (SMD) packages that can withstand a peak reflow temperature of 245°C.
All components are supplied in tape and reel packaging for easy handling and storage.

Technical Parameters of PoE Magnetics:

Product Type	PoE Ethernet Transformer LAN Discrete Modules
Number of Channels/Ports	Single
Data Rate	1000BASE-T
PoE Power	30W PoE 4 Pair
Mounting	SMT
Dimension	15.110.04.0mm
Application	ETHERNET TRANSFORMER/CHOKE
Standards	IEEE 802.3ab/af
RoHS Status	Fully ROHS Compliant
Moisture Sensitive Level	1
Maximum Peak Solder Temperature	245°C

Applications:

1. IP Phones
2. Wireless Access Points
3. Video Surveillance
4. Point-of-Sale Terminals
5. Networking and Security Devices
6. Industrial Control
7. Telecom Infrastructure

HB5006HLT HXB5008HLT Schematics:
