Product Details
Place of Origin: CHINA
Brand Name: LINK-PP
Certification: ROHS,ISO,REACH,UL Certified
Model Number: SS-700810-NF（LPJE180-0NNL）
Payment & Shipping Terms
Minimum Order Quantity: Free Samples Available
Price: $0.28-$0.68
Packaging Details: Tray
Delivery Time: 3-6 days
Payment Terms: L/C, T/T, Western Union, MoneyGram, T/T
Supply Ability: 6500Kpcs Per Month
Product Type: |
8P8C Modular Jack |
Orientation: |
Horizontal |
Number Of Ports: |
1X1 |
Shielding: |
Unshielded |
Tab Direction: |
Tab Down |
Profile: |
Micro |
LED: |
Does Not Contain LED |
Gender: |
Jack (Female) |
Product Type: |
8P8C Modular Jack |
Orientation: |
Horizontal |
Number Of Ports: |
1X1 |
Shielding: |
Unshielded |
Tab Direction: |
Tab Down |
Profile: |
Micro |
LED: |
Does Not Contain LED |
Gender: |
Jack (Female) |
| Title |
Unshielded Horizontal RJ45 1*1 Connector |
|---|---|
| Connector Type | Jack |
| Number of Ports | 1x1 |
| Number of Positions/Contacts |
8p8c (RJ45, Ethernet) |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Mounting Style | PCB Mount |
| Shielding | Unshielded |
| Performance Rating | Cat5 |
| Features | Board Lock |
| LED Option | NO |
| Operating Temperature | -40°C ~ 85°C |
| RoHS Status | ROHS3 Compliant |
ELECTRICAL:
1. VOLTAGE RATING: 125V AC.
2. CURRENT RATING:1.5A.
3. CONTACT RESISTANCE: 30 m2 MAX.
4. INSULATION RESISTANCE: 500 M2 MIN @ 500V DC.
5. DIELECTRIC STRENGTH: 1000V AC 50Hz Or 60Hz, 1MIN.
MECHANICAL :
1. MATING/UNMATING FORCE:2.2KG.F MAX.
2. RETENTION STRENGTH: 3.OKG.F MIN BETWEEN JACK AND PLUG.
3. OPERATING LIFE:750 CYCLES MIN.
ENVIRONMENTAL:
1. STORAGE TEMPERATURE RANGE :-40℃ - + 85℃ RELATIVE HUMIDITY<70%.
2. OPERATION TEMPERATURE RANGE:-40℃ - +85℃.
3. Wave solder tip temperature and time: 250℃, 5 Sec.
4. Ul Certification: File Number E484635.
