Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: LPJ0011BBNL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.06-$0.8
Packaging Details: 50pcs/tray,1200pcs/carton, Carton size/32*30*31cm, G.W./carton/8.5kg
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4200K-PCS/Month
Product Type: |
Single Port Jack |
Number Of Ports: |
1X1 |
Orientation: |
Vertical |
Shielding: |
No |
Number Of Contacts: |
4 |
Number Of Positions: |
6 |
Profile: |
Low |
LED: |
Without |
Product Type: |
Single Port Jack |
Number Of Ports: |
1X1 |
Orientation: |
Vertical |
Shielding: |
No |
Number Of Contacts: |
4 |
Number Of Positions: |
6 |
Profile: |
Low |
LED: |
Without |
Notes of 6P4C Vertical RJ45 Jack:
MATERIAL:
1. CONTACT WIRE: 0.46MM DIAMETER PHOSPHOR BRONZE OPTIONAL GOLD PLATING OVER NICKEL
2. DURABILITY: 1000 MATING CYCLES MIN
ELECTRICAL:
1. CURRENT RATING: 1. 5A
2. VOLTAGE RATING: 125VAC RMS
3. CONTACT RESISTANCE: 20MΩ MAX
4. INSULATION RESISTANCE:100MΩ MIN
5. WITHSTANDING VOLTAGE:1000V AC FOR 1min.
6. GOLD PLATING: (GOLD FLASH:1.5; 3; 6; 15; 30; 50)U" INCH
7. (1) STORAGE TEMPERATURE RANGE:-40℃ to +85℃
(2) 0PERTIONTEMPERATURE RANGE: -40℃ to +85℃
(3)WAVE SOLDER TEMPERTURE: 230C to 250℃5~10 SEC.
