Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: J0011D21BNL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4600K.PCS/Month
Part Number: |
J0011D21BNL |
Made In China: |
SM-LPJ0011ABNL |
Ethernet: |
10/100Base-TX |
Project Application: |
Wireless Port |
LEDs: |
Green/Yellow |
Family: |
Magnetics Rj45 Female Jack |
Part Number: |
J0011D21BNL |
Made In China: |
SM-LPJ0011ABNL |
Ethernet: |
10/100Base-TX |
Project Application: |
Wireless Port |
LEDs: |
Green/Yellow |
Family: |
Magnetics Rj45 Female Jack |
PulseJack J0011D21BNL Connector 8P8C Rj45 10/100Base-T W/LEDs
ELECTRICAL SPECFICATIONS: @25℃
1.Turn Ratio(%%P2%):
TX=1CT∶1CT RX=1CT∶1CT
2.Inductance OCL: 350uH MIN
@100KHz 0.1V 8mA DC Bias
3.Insertion Loss:
-1.0dB MAX @ 1.0-100MHz
4.Return Loss:
-18dB MIN @ 1-30MHz
-15dB MIN @ 30-60MHz
-12dB MIN @ 60-80MHz
-10dB MIN @ 80-100MHz
5.Cross talk:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
6.Common Mode Rejection:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
7.Hipot: 1500Vrms
8.Operating Temperature Range: 0℃ TO 70℃
