Product Details
Place of Origin: Guangdong, China
Brand Name: LINK-PP
Certification: RoHS Compliant
Model Number: 615006141121
Payment & Shipping Terms
Minimum Order Quantity: 50pcs
Price: $0.3-$0.9
Packaging Details: Tray
Delivery Time: 3-7 days
Payment Terms: D/A, D/P, Western Union, MoneyGram
Supply Ability: 5KK/Month
Connector Type: |
Female Modular Jack |
Part Number: |
615006141121 |
Category Specification Connector Type Modular Jack (Female) Configuration: |
1x1 (Single Port) |
Contacts: |
6 Position, 6 Contact (6P6C) |
Mounting: |
Through Hole, Right Angle |
Termination: |
Solder |
Shielding: |
Unshielded |
Operating Temperature: |
-40 °C Up To +85 °C |
Orientation: |
Tab Down |
Flammability Rating: |
UL 94 V-0 |
Connector Type: |
Female Modular Jack |
Part Number: |
615006141121 |
Category Specification Connector Type Modular Jack (Female) Configuration: |
1x1 (Single Port) |
Contacts: |
6 Position, 6 Contact (6P6C) |
Mounting: |
Through Hole, Right Angle |
Termination: |
Solder |
Shielding: |
Unshielded |
Operating Temperature: |
-40 °C Up To +85 °C |
Orientation: |
Tab Down |
Flammability Rating: |
UL 94 V-0 |
✔ Wave Soldering Optimized – Ideal for high-volume PCB assembly
✔ Universal Compatibility – Works with RJ11 (6P4C) and RJ12 (6P6C) plugs
✔ Robust Construction – Gold-plated contacts resist corrosion
✔ Space-Efficient – Right-angle mounting saves PCB space
✔ Safety Certified – Meets UL 94 V-0 flammability standards
| Category | Specification | Notes |
|---|---|---|
| Product Type | 6P6C Modular Jack | Female connector |
| Configuration | 1 Port (1x1) | Single-port design |
| Contact Arrangement | 6 Position 6 Contact (6P6C) | Compatible with the RJ12 standard |
| Mounting Type | Through Hole | Right-angle orientation |
| Termination Method | Solder Cup | Wave solder compatible |
| Current Rating | 1.5A | Max continuous current |
| Voltage Rating | 120V AC | Rated voltage |
| Contact Material | Copper Alloy | Gold plated contacts |
| Contact Resistance | ≤20mΩ | Initial value |
| Insulation Resistance | ≥500MΩ | At 500VDC |
| Dielectric Strength | 1000V AC for 1 minute | Between contacts and shell |
| Operating Temperature | -40°C to +85°C | Storage temperature same |
| Flammability Rating | UL 94 V-0 | Flame retardant |
| Housing Material | High-temperature thermoplastic | Black color |
| Insertion Cycles | ≥500 cycles | Minimum durability |
| Contact Plating | Gold over nickel | 0.76μm min gold thickness |
| Packaging | Tray | Standard packaging |
