Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,RoHS,REACH,ISO
Model Number: 7490220120
Payment & Shipping Terms
Minimum Order Quantity: 10pcs
Price: 30% discount
Packaging Details: Tray
Delivery Time: Sufficient stock, fast delivery
Payment Terms: TT, NET30/60/90 Days
Supply Ability: 5KK/Month
Type: |
PoE Transformer Modules |
Data Rate: |
10/100/1000BASE-T |
Inductance: |
350 UH |
Isolation Voltage: |
1500Vrms |
Mounting: |
SMT |
Operating Temperature: |
-40 °C Up To +105 °C |
Part Number: |
7490220120 |
PoE Support: |
4PPoE (up To 350 MA) |
Type: |
PoE Transformer Modules |
Data Rate: |
10/100/1000BASE-T |
Inductance: |
350 UH |
Isolation Voltage: |
1500Vrms |
Mounting: |
SMT |
Operating Temperature: |
-40 °C Up To +105 °C |
Part Number: |
7490220120 |
PoE Support: |
4PPoE (up To 350 MA) |
|
Properties |
Symbol |
Test conditions |
Value |
Unit |
Tol. |
|---|---|---|---|---|---|
|
Inductance |
L |
100 kHz / 100 mV @ 8 mA |
350 |
µH |
min. |
|
Insulation Test Voltage |
VT |
1 min. |
1500 |
V (RMS) |
min. |
|
Insertion Loss |
IL |
1-100 MHz |
-1 |
dB |
max. |
|
Return Loss |
RL |
1-30 MHz |
-18 |
dB |
min. |
|
Return Loss |
RL |
30-60 MHz |
-14 |
dB |
min. |
|
Return Loss |
RL |
60-80 MHz |
-12 |
dB |
min. |
|
Return Loss |
RL |
80-100 MHz |
-10 |
dB |
min. |
|
Differential to Common Mode Rejection Ratio |
DCMR |
1-30 MHz |
-40 |
dB |
min. |
|
Differential to Common Mode Rejection Ratio |
DCMR |
30-60 MHz |
-35 |
dB |
min. |
|
Differential to Common Mode Rejection Ratio |
DCMR |
60-100 MHz |
-30 |
dB |
min. |
|
Crosstalk |
CT |
1-60 MHz |
-35 |
dB |
min. |
|
Crosstalk |
CT |
60-100 MHz |
-30 |
dB |
min. |
|
Common Mode Rejection Ratio |
CMRR |
1-30 MHz |
-40 |
dB |
min. |
|
Common Mode Rejection Ratio |
CMRR |
30-60 MHz |
-35 |
dB |
min. |
|
Common Mode Rejection Ratio |
CMRR |
60-100 MHz |
-30 |
dB |
min. |
|
Turns Ratio |
n |
|
1:1 |
|
±2% |
|
Data rate |
|
|
10/100/1000BASE-T |
|
|
General Information:
|
Property |
Value |
|---|---|
|
Operating Temperature |
-40 °C up to +105 °C |
|
Storage Conditions (in original packaging) |
< 40 °C ; < 75 % RH |
|
Moisture Sensitivity Level (MSL) |
1 |
|
Test conditions of Electrical Properties |
+20 °C, 33 % RH if not specified differently |
