Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: RoHS, REACH
Model Number: 615008160121
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: OEM Price
Packaging Details: Tray Package: 50 pcs in 1 tray,24tray in 1 carton, which is 32*30*31 , 8.5 KGS (1200pcs) of each carton
Delivery Time: Around 3-5 Days
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Status: |
Active |
Number Of Pins: |
8P8C |
EMI Tabs: |
No |
Mount Type: |
THT |
Tab: |
Up |
LAN Category: |
CAT6 |
LED Indicators: |
Wthout |
Mount: |
THT |
Status: |
Active |
Number Of Pins: |
8P8C |
EMI Tabs: |
No |
Mount Type: |
THT |
Tab: |
Up |
LAN Category: |
CAT6 |
LED Indicators: |
Wthout |
Mount: |
THT |
| Series | 8P8C RJ45 Connector |
|---|---|
| Part Number | 615008160121 |
| Number of Ports | 1x1 Port |
| Orientation | 90° Angle (Right) |
| Mounting Type | Through Hole |
| Gender | Female Jack |
| Insulation Resistance | 1000 MΩ (Min) |
| Contact Resistance | 20 mΩ (Max) |
| Current Rating | 1.5 A |
| Voltage Rating | 125 V (AC) |
| Dielectric Withstanding Voltage | 1000 V (AC) for 60 seconds |
| Operating Temperature | -40°C to +85°C |
| Flammability Rating | UL94 V-0 |
| Shield | Shielded |
| Durability (Mating Cycles) | 750 Cycles |
| Recommended Solder Process | Wave Soldering |
Selective Gold (Au): A thin layer of gold is applied to the critical contact mating area. Gold is used because it is highly resistant to corrosion and oxidation, ensuring a low-resistance, stable electrical connection over time.
Nickel (Ni) Underplating: A layer of nickel is applied beneath the gold. This underplate serves as a barrier to prevent the copper from migrating into the gold layer and also enhances the overall durability and corrosion resistance.
