Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: RoHS Compliant
Model Number: 1-1840860-4
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.09-$2.2
Packaging Details: T&R
Delivery Time: About 3 Days
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 5KK/Month
Part Number: |
1-1840860-4 |
Number Of Ports: |
Stacked 2x6 Ports |
Contact Finish: |
Gold |
Orientation: |
Angle (Right) |
Magnetic: |
With |
Termination: |
Wave Soldering |
Data Rate: |
10/100/1000 BASE-T |
Part Number: |
1-1840860-4 |
Number Of Ports: |
Stacked 2x6 Ports |
Contact Finish: |
Gold |
Orientation: |
Angle (Right) |
Magnetic: |
With |
Termination: |
Wave Soldering |
Data Rate: |
10/100/1000 BASE-T |
| Products Category | Integrated Connector Modules |
|---|---|
| Part Number | 1-1840860-4 |
| Type | RJ45 Magnetic Jack |
| Gender | Female |
| Configuration | 2x6 |
| Dimension | 41.20x87.01x25.50mm |
| Shielding | Shielded |
| Speed | 1000 Base-T |
| Mounting Style | Through Hole |
| Mounting Angle | Right Angle |
| Termination Style | Wave Solder |
| Minimum Operating Temperature | 0°C |
| Maximum Operating Temperature | +70°C |
| LED Indicator Colors | G/Y (Left) and G/Y (Right) |
| Applications | 10/100/1000 BASE-T Ethernet applications |
| Return Loss | -16dB min from 1MHz to 100MHz |
| Insertion Loss | -1.0dB max from 1MHz to 100MHz |
| Crosstalk | -35dB min from 1MHz to 100MHz |
| Common Mode Rejection | -30dB min from 1MHz to 100MHz |
| Isolation Voltage | 1500Vrms, for 60 seconds |
