Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: 749013011A
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$0.9
Packaging Details: T&R
Delivery Time: 3-5 days
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Part Number: |
749013011A |
Category: |
LAN Transformer / Ethernet Magnetics |
Mounting Type: |
Surface Mount (SMT) |
Data Rate: |
10/100Base-TX |
PoE Support: |
Yes |
Operating Temperature: |
-40 °C Up To +105 °C |
Part Number: |
749013011A |
Category: |
LAN Transformer / Ethernet Magnetics |
Mounting Type: |
Surface Mount (SMT) |
Data Rate: |
10/100Base-TX |
PoE Support: |
Yes |
Operating Temperature: |
-40 °C Up To +105 °C |
The 749013011A is a high-performance LAN transformer specifically designed for 10/100 Base-T Ethernet applications with Power over Ethernet (PoE) support. This SMT transformer provides signal integrity, electrical isolation, and efficient power transfer over Ethernet cables, fully compliant with IEEE 802.3 and IEEE 802.3af standards.
It is ideal for industrial automation, IP communication, and IoT applications where reliable Ethernet connectivity and PoE power delivery are required.
|
|---|
The 749013011A supports PoE operation with up to 350 mA current per center tap, allowing both data transmission and DC power delivery through a single Ethernet cable.
It is optimized for thermal reliability — ensuring stable performance up to +105°C component temperature under full PoE load.
