HFJ11-1G06ERL FastJack Tab-Down Gigabit Short Body RJ45 Female PCB Connector

Name: HFJ11-1G06ERL FastJack Tab-Down Gigabit Short Body RJ45 Female PCB Connector
Brand: LINK-PP
SKU: HFJ11-1G06ERL
Price: 0.09 USD
Availability: InStock
Rating: 4.8 (166 reviews)

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: HFJ11-1G06ERL

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000/25K

Price: $0.09-$1.85

Packaging Details: 50pcs/tray,1200pcs/carton

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 250000-320000/Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                rj45 smd connector, shielded rj45 plugs


Specification:	HFJ11-1G06ERL	Part No:	LPJG0917CNL
Munafactuer:	LINK-PP	Application:	1x 10/100/1000Mbps
Termination:	Solder	Samples:	Available Free

Specification:	HFJ11-1G06ERL
Part No:	LPJG0917CNL
Munafactuer:	LINK-PP
Application:	1x 10/100/1000Mbps
Termination:	Solder
Samples:	Available Free

HFJ11-1G06ERL FastJack Tab-Down Gigabit Short Body RJ45 Female PCB Connector

FastJack ™ 1x1 Tab-Down Gigabit Short Body RJ45

1.1x Gigabit (10/100/1000) Ethernet RJ45
2.IEEE802.3ab Compliant
3.350uH min OCL at 8mA DC Bias Across the Full Temp Range
4.30µ” Gold Plating (min) on Contacts
5.100% Compliance Testing
6.1500Vrms Hi-Pot
7.Proprietary Robust Contact Design

8.Specification: 【HFJ11-1G06ERL】

9.Cross Model:【LPJG0917CNL】

Description

Electrical Specifications @ 25℃
1.Turns Ratio:
TX=1:1 RX=1:1
2.INDUCTANCE(@100KHz,100mV,8mA DC BIAS):
J1-J2;J3-J6;J4-J5;J7-J8: 350uH min
3.Insertion Loss:
0.3～100MHz:-1.2dB Max
4.Return Loss(dB Min.load 100Ω):
1～30MHz:-16 40MHz:-13.5
50MHz:-11.5 60～80MHz:-10
5.Crosstalk(dB Min):
30MHz:-40 60MHz:-36
100MHz:-30
6.Differential to Common Mode Rejection:
30MHz:-35dB Min 60MHz:-32dB Min
100MHz:-30dB Min
7.Isolation Voltage:1500Vrms
8.Operating Temperature Range: 0℃～70℃.

Competitive Advantage

18 years production experience,

2600 staff,

100% test

Flexible delivery time

EMS Application

Built-in Flexible PCB Assembly; Rigid-Flexible PCB Assembly; Microelectronic, Flip Chip; Microelectronic, Chip On Board; Optoelectronic Assembly; RF / Wireless Assembly; Through Hole Assembly; Surface Mount Assembly; System Assembly; Printed Circuit Board Assembly
