Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: HFJ11-1G41E-L12RL
Document: LPJG0843GENL.pdf
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.65-$1.05
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: In Stock Ship Within 3 Days
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 250000-320000/Month
Part Number: |
HFJ11-1G41E-L12RL |
Mass Production: |
LPJG0843GENL |
Application: |
10/100/1000 Base-T, AutoMDIX |
Configuration: |
1x1 (1 Port, 1 Row) |
Termination Style: |
Solder |
Mount Style: |
Through Hole |
Contact Finish / Plating: |
Gold, 30.0uin (0.76um) Minimum |
Flammability Rating: |
UL 94 V-0 |
Part Number: |
HFJ11-1G41E-L12RL |
Mass Production: |
LPJG0843GENL |
Application: |
10/100/1000 Base-T, AutoMDIX |
Configuration: |
1x1 (1 Port, 1 Row) |
Termination Style: |
Solder |
Mount Style: |
Through Hole |
Contact Finish / Plating: |
Gold, 30.0uin (0.76um) Minimum |
Flammability Rating: |
UL 94 V-0 |
The HFJ11-1G41E-L12RL from the FastJack series is a premium-grade, 1x1 Tab-Down Gigabit RJ45 connector designed for high-performance networking applications. Engineered for 10/100/1000 Base-T and AutoMDIX environments, this short-body magnetic jack ensures space-saving PCB integration without compromising signal integrity.
Fully compliant with IEEE802.3ab standards, the HFJ11-1G41E-L12RL features a proprietary robust contact design with 30µ” gold plating to ensure long-term durability and reliable mating. With an integrated shield, EMI fingers, and built-in Green/Yellow LEDs for network status indication, this active component is 100% compliance-tested for immediate deployment in enterprise, industrial, and consumer networking hardware.
| Item | Specification |
|---|---|
| Product Part Number | HFJ11-1G41E-L12RL |
| Product Series | FastJack |
| Connector Type | RJ45 |
| Configuration | 1x1 |
| Number of Ports | 1 Port |
| Positions / Contacts per Port | 8P8C |
| Number of Positions | 14 Position |
| Number of Rows | 1 |
| Performance Category | Cat 5e |
| Application | 10/100/1000 Base-T |
| Shielding | Shielded, EMI Fingers |
| Mounting Style | Through Hole |
| Mounting Angle | Right Angle |
| Orientation | 90° Angle (Right) |
| Termination Style | Solder |
| Tab Direction | Tab Down |
| LED Color | Green / Yellow |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Pitch | 2.54 mm |
| Operating Temperature | 0°C to +70°C |
| Flammability Rating | UL 94 V-0 |
| Packaging | Tube |
| Part Status | Active |
The HFJ11-1G41E-L12RL is designed to support stable Gigabit Ethernet operation with strong signal integrity characteristics. Its return loss performance is specified as:
These values make the connector suitable for Ethernet designs where transmission quality and compliance are important. The high OCL performance and EMI shielding further support dependable operation in noise-sensitive applications.
Each connector is built with a focus on consistency and compliance. The HFJ11-1G41E-L12RL features:
These qualities make it a dependable choice for OEMs and manufacturers who need consistent production quality and stable field performance.
HFJ11-1G41E-L12RL FastJack shielded 1x1 tab-down Gigabit RJ45 connector featuring 10/100/1000 Base-T support, integrated magnetics, EMI fingers, and Green/Yellow LEDs.
The HFJ11-1G41E-L12RL is a 1x1 tab-down Gigabit RJ45 connector designed for 10/100/1000 Base-T Ethernet applications.
Yes. It supports 10/100/1000 Base-T Gigabit Ethernet and is IEEE 802.3ab compliant.
Yes. It is a shielded RJ45 connector with EMI fingers for improved interference protection.
It uses a through-hole, right-angle mounting style with solder termination.
The connector has a tab-down orientation.
The connector uses Green / Yellow LED indicators.
